Air-sprung fork? Let us introduce you to your new friend, Judy. Discerning when it comes to your drivetrain? You’ll find no fault—and no grade too steep—with a wide-range Shimano Deore 1x11 drivetrain.
EMAIL: sales@steedcycles.com
PHONE: 604-987-2168
Frame Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Seat Binder Alloy, quick release, 34.9
Fork RockShox Judy, Solo Air, Turnkey damper, 46mm offset, QR, 80/90/100mm travel (size-specific), steel steerer
Stem 3D-forged alloy, 31.8mm, 7-degree rise
Handlebars Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Grips Specialized MTB Grip, lock-on
Saddle Bridge Sport, Steel rails, 155/143mm
SeatPost Alloy, 2-bolt clamp, 30.9mm
Front Brake Shimano BR-MT200, hydraulic disc, 180mm
Rear Brake Shimano BR-MT200, hydraulic disc, 180mm
Rear Derailleur Shimano Deore M5100, SGS, 11-speed
Shift Levers Shimano Deore M5100, 11-speed
Cassette Shimano Deore, 11spd, 11-51t
Chain KMC X11EPT, 11-speed, anti-corrosion coating w/ reusable Missing Link™
Crankset Stout 1x, forged alloy
Bottom Bracket Square-tapered, 73mm, internal bearings, 122.5mm spindle
Rims Specialized Alloy, hookless, Tubeless ready, 25mm inner width
Front Hub Formula DC-20, 6-Bolt, disc, 100x9mm spacing, quick-release
Rear Hub Formula DC-22, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Spokes Stainless, 14g
Front Tire Specialized Fast Trak, Control Casing, T5 Compound, 29x2.35
Rear Tire Specialized Fast Trak, Control Casing, T5 Compound, 29x2.35
Inner Tubes Presta, 40mm valve
Pedals SBC-54 Flat pedal
| XS - 27.5 | S - 27.5 | M - 27.5 | S - 29 | M - 29 | L - 29 | XL - 29 | XXL - 29 | ||
|---|---|---|---|---|---|---|---|---|---|
| A | Reach | 375 | 395 | 405 | 415 | 425 | 445 | 465 | 485 |
| B | Stack | 559 | 573 | 607 | 589 | 616 | 626 | 640 | 654 |
| C | Head Tube Angle | 68° | 68° | 68.5° | 68° | 68.5° | 68.5° | 68.5° | 68.5° |
| D | Front Centre | 630 | 656 | 672 | 682 | 696 | 719 | 745 | 770 |
| E | Bottom Bracket Drop | 43 | 43 | 62 | 43 | 62 | 62 | 62 | 62 |
| F | Wheelbase | 1067 | 1092 | 1105 | 1118 | 1128 | 1152 | 1178 | 1203 |
| G | Chainstay Length | 440 | 440 | 440 | 440 | 440 | 440 | 440 | 440 |
| H | Head Tube Length | 95 | 100 | 95 | 105 | 95 | 105 | 120 | 135 |
| I | Top Tube Length | 541 | 565 | 586 | 589 | 608 | 630 | 654 | 679 |
| J | Seat Tube Angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| K | Standover Height | 658 | 695 | 732 | 735 | 754 | 781 | 820 | 853 |
| All measurements in degrees or millimetres | |||||||||
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | Imperial | Metric |
|---|---|---|
| XXS | 4'3" - 4'9" | 130 - 145cm |
| XS | 4'8" - 5'1" | 142 - 155cm |
| S | 5'0" - 5'5" | 153 - 165cm |
| M | 5'4" - 5'10" | 163 - 178cm |
| L | 5'9" - 6'1" | 175 - 185cm |
| XL | 6'0" - 6'5" | 183 - 195cm |
| XXL | 6'4" - 6'9" | 193 - 206cm |
