Specialized Epic 8 Evo Expert Di2
Specifications
Frame FACT 11m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, SWAT downtube storage, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel
SWAT SWAT internal downtube storage
Seat Binder Specialized Alloy, 34.9, Steel bolt
Rear Shock FOX FLOAT Performance Elite, EVOL LV, Ride Dynamics Tuned, 2-position compression adjust, 190x45mm
Fork FOX 34 SL Performance Elite, GRIP X Damper, HSC, LSC, LSR adjust, 130mm travel, 44mm offset, 15x110mm
Front Brake Shimano XT 8200, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake himano XT 8200, 4-piston caliper, hydraulic disc, 180mm rotor
Shift Levers Shimano XT Di2
Chain Shimano XT
Cassette Shimano XT M8200, 12-speed, 10-51t
Bottom Bracket Shimano, BB-MT801, Threaded
Crankset Shimano XT 8200, 170mm
Rear Derailleur Shimano XT Di2, 12-speed
Chainrings 32T
Front Wheel Roval Control SL V, Hookless carbon, 29mm inner width, tubeless ready, DT Swiss 370 hub, Sapim D-Light Straight Pull, 6 bolt
Rear Wheel Roval Control SL V, Hookless carbon, 29mm inner width, tubeless ready, DT Swiss 370 hub, Sapim D-Light Straight Pull, 6 bolt
Front Tire Specialized Purgatory, GRID Casing, T9 Compound, 2Bliss Ready, 29x2.4
Rear Tire Specialized Ground Control, Grid Lite Casing, T5/T7 Compound, 2Bliss Ready, 29x2.35
Inner Tubes Specialized Turbo Tube
Stem Alloy Stem, 35mm clamp, 60mm
Saddle Body Geometry Power Comp, steel rails
Handlebars Specialized Alloy, 20mm rise, 35mm
SeatPost X-Fusion Manic, 30.9, XS-SM: 125mm, M: 150mm, L-XL: 170mm Travel, 0mm offset
Grips Specialized Trail Grips
Weight 11.85kg (26 lb, 2.0 oz) - Size MD
Geometry
| XS | S | M | L | XL | ||
|---|---|---|---|---|---|---|
| HI | LO | HI | LO | HI | LO | HI | LO | HI | LO | ||
| A | Reach | 390 | 420 | 450 | 475 | 500 |
| B | Stack | 603 | 597 | 598 | 610 | 628 |
| C | Head Tube Angle | 66.4° | 65.9° | 66.4° | 65.9° | 66.4° | 65.9° | 66.4° | 65.9° | 66.4° | 65.9° |
| D | Seat Tube Length | 370 | 390 | 410 | 450 | 500 |
| E | Front Center | 687 | 716 | 747 | 778 | 811 |
| F | Bottom Bracket Height | 323/318 | 329/324 | 331/326 | 333/328 | 333/328 |
| G | Bottom Bracket Drop | 52 | 46 | 44 | 42 | 42 |
| H | Wheelbase | 1117 | 1147 | 1179 | 1210 | 1243 |
| I | Chainstay Length | 435 | 435 | 435 | 435 | 435 |
| J | Head Tube Length | 92 | 92 | 95 | 110 | 130 |
| K | Top Tube Length | 535 | 569 | 605 | 633 | 662 |
| L | Seat Tube Angle | 76.5° | 76° | 75.5° | 75.5° | 75.5° |
| M | Standover Height | 748 | 755 | 760 | 769 | 774 |
| All measurements in degrees or millimetres | ||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | Imperial | Metric |
|---|---|---|
| XS | 4'10" - 5'1" | 148 - 155cm |
| S | 5'2" - 5'5" | 158 - 165cm |
| M | 5'5" - 5'10" | 165 - 178cm |
| L | 5'10" - 6'1" | 178 - 185cm |
| XL | 6'1" - 6'4" | 185 - 193cm |
Part Numbers
| Size | Model Number | Gloss Carbon / White | Satin Sandstone Metallic |
|---|---|---|
| XS | 90326-3401 | 90326-3501 |
| S | 90326-3402 | 90326-3502 |
| M | 90326-3403 | 90326-3503 |
| L | 90326-3404 | 90326-3504 |
| XL | 90326-3405 | 90326-3505 |
