DESCRIPTION
Specialized's Epic is synonymous with top level cross country racing - not only is it one of the most high performing bikes, but it's also won countless races with its cutting edge, lightweight platform. Specialized is known for positioning itself at the cutting edge of bike technology, and as a World Cup race platform, the Epic has always been at the forefront of that.
The Epic 8 then is their most technologically advanced XC bike yet, and while everybody expects it to be lighter, faster, more efficient, Specialized has focussed a lot of energy on also making it ultra-capable when it comes time to descend, because modern XC races are not just won on the way up.
Specification
Frame
FACT 11m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, SWAT downtube storage, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel
Seat Binder
Specialized Alloy, 34.9, Steel bolt
SWAT
SWAT internal downtube storage
Fork
RockShox SID Select, Ride Dynamics developed 3 position, TwistLoc remote adjust, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Rear Shock
RockShox SIDLuxe Select+, Ride Dynamics developed 3 position, TwistLoc remote adjust, Solo Air, 190x45mm
Saddle
Body Geometry Power Sport, steel rails
SeatPost
X-Fusion Manic, 30.9, 100/125/150/175 Travel, 0mm offset
Grips
SRAM Slip on with Twist-Loc
Handlebars
Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Front Brake
SRAM Level Bronze Stealth, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake
SRAM Level Bronze Stealth, 4-piston caliper, hydraulic disc, 160mm rotor
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
Crankset
SRAM X1000 Eagle, DUB, 165/170/175mm
Rear Derailleur
SRAM GX Eagle, 12-speed
Shift Levers
SRAM GX, trigger, 12-speed
Chain
SRAM NX Eagle, 12-speed
Cassette
SRAM XG-1275, 12-speed, 10-52t
Chainrings
Steel, 32T
Rear Hub
Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
Spokes
DT Swiss Industry
Front Tire
Specialized Fast Trak, Control Casing, T7 Compound, 29x2.35
Rims
Specialized Alloy 29, 28mm internal width, tubeless
Rear Tire
Specialized Renegade, Control Casing, T5 Compound, 29x2.35
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Inner Tubes
Standard, Presta Valve
Weight
11.7kg (25 lb, 12.7 oz) - Size MD
*All specifications are subject to change without notice
Geometry
| XS | S | M | L | XL | ||
|---|---|---|---|---|---|---|
| HI/LO | HI/LO | HI/LO | HI/LO | HI/LO | ||
| A | Reach (lo) | 390 | 420 | 450 | 475 | 500 |
| B | Stack | 603 | 597 | 598 | 610 | 628 |
| C | Head Tube Angle | 66.4|65.9 | 66.4|65.9 | 66.4|65.9 | 66.4|65.9 | 66.4|65.9 |
| D | Seat Tube Length | 370 | 390 | 410 | 450 | 500 |
| E | Front Center | 687 | 716 | 747 | 778 | 811 |
| F | Bottom Bracket Height | 323|318 | 329|324 | 331|326 | 333|328 | 333|328 |
| G | Bottom Bracket Drop (lo) | 52 | 46 | 44 | 42 | 42 |
| H | Wheelbase | 1117 | 1147 | 1179 | 1210 | 1243 |
| I | Chainstay Length | 435 | 435 | 435 | 435 | 435 |
| J | Head Tube Length | 92 | 92 | 95 | 110 | 130 |
| K | Top Tube Length | 535 | 569 | 605 | 633 | 662 |
| L | Seat Tube Angle | 76.5 | 76 | 75.5 | 75.5 | 75.5 |
| M | Standover Height | 748 | 755 | 760 | 769 | 774 |
*ALL MEASUREMENTS IN DEGREES OR MILLIMETRES
Size Guide
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| XS | 4'10" - 5'1" | 148 - 155cm |
| 49 | 5'1" - 5'5" | 155 - 163cm |
| S | 5'2" - 5'5" | 158 - 165cm |
| M | 5'5" - 5'10" | 165 - 178cm |
| L | 5'10" - 6'1" | 178 - 185cm |
| XL | 6'1" - 6'4" | 185 - 193cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
