DESCRIPTION
Whether your goal is to escape on gravel back roads, far from cars and crowds, or drop the hammer at the front of your favorite gravel race, no bike does it better than the new Diverge. It’s just maybe the most fun bike we’ve ever made, delivering a ride that’s quick and lively under power but stable and confidence-inspiring when the terrain gets rough. From Future Shock 2.0 and gravel geometry to internal storage and category-leading tire clearance, the Diverge represents everything we’ve learned over more than 40 years of riding road, gravel, and dirt. The Diverge writes an entirely new chapter in the gravel bike category, so you can dream up entirely new rides. It’s the ultimate getaway vehicle.
The Diverge Expert is built with the perfect mix of SRAM’s Rival, GX, and NX components for fast, efficient shifting with an 11-50 cassette to ensure you have the gearing to tackle any ride. The bike rolls on the Roval Terra C wheels with 42mm Pathfinder Pro tires. Adventure Gear alloy handlebars, a Roval Terra carbon seatpost, and a Power Expert saddle complete.
- The more capable your bike, the bigger your rides get, so Diverge borrows SWAT internal storage from the legendary Stumpy. The SWAT door lets you utilize space in the down tube to store tools, a flat kit, nutrition, and even our SWAT Jacket. It keeps weight off your body and low in the bike for better handling and makes you more self-sufficient, so get out there. SWAT’s got your back.
- We tossed gravel geometry status quo out the window. The new Diverge has the most progressive geometry we’ve ever created for a drop bar bike, giving riders a capable and stable bike in the dirt that still feels responsive and nimble on the road. We’ve increased the frame’s reach, introduced a slacker head tube and a longer offset fork. All this creates incredible confidence with a planted feeling in the dirt while spec’ing shorter stems keeps the overall cockpit length the same and the steering lively. We’ve kept the bike’s BB low to increase stability but high enough to utilize with 650b wheels if that’s your jam.
- Speed, control, and confidence - Future Shock 2.0 is the ultimate technology for the gravel rider. With 20mm of axial compliance and a hydraulic damper, Future Shock 2.0 suspends the rider, not the bike. This keeps you confident and in control, able to keep the power down and stay off the brakes over rough dirt roads and in thick, loose gravel while keeping your hands, arms, and neck fresh. Since Future Shock 2.0’s damper is adjustable, you’ll be ready for the rough stuff and efficient on smooth pavement.
- We’ve given the Diverge plenty of rack mounts, including fork and top tube mounts, to ensure you can take what you need, no matter how far you plan to go or how long you plan to stay out.
- Nothing unlocks a bike’s capability like tire clearance, so we gave the new Diverge a whopping 47mm of tire clearance with a 700c wheel and 2.1” with a 650b wheel. Thanks to a drive-side chain stay utilizing a solid beam of carbon behind the chainrings, we’ve created clearance without using a fragile dropped chain stay design or increasing chain stay length.
- With a FACT 9r carbon frame, the Diverge Expert frame is incredibly capable and race bike light. Pin it for your local dirt climb KOM, or grind up a giant backcountry peak, the light and lively Diverge will get you there faster.
Specifications
Frame
Specialized Diverge FACT 9r carbon, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc
Fork
Future Shock 2.0 w/ Damper, Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount
Saddle
Body Geometry Power Expert
Stem
Future Stem, Pro
SeatPost
Roval Terra Carbon Seat Post, 20mm Offset
Seat Binder
Specialized Alloy, 30.8mm
Handlebars
Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare
Tape
Supacaz Super Sticky Kush
Front Brake
SRAM Rival eTAP AXS, hydraulic disc
Rear Brake
SRAM Rival eTAP AXS, hydraulic disc
Chainring
40T
Shift Levers
SRAM Rival ETAP AXS
Rear Derailleur
SRAM GX Eagle AXS
Bottom Bracket
SRAM DUB BSA 68
Crankset
SRAM Rival 1 Wide
Chain
SRAM GX Eagle, 12-speed
Cassette
SRAM NX Eagle, 12-speed, 11-50t
Inner Tubes
48mm Presta valve
Rear Wheel
Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 Star Ratchet hub, 24h, DT Swiss Comp Race spokes
Front Wheel
Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 Star Ratchet hub, 24h, DT Swiss Comp Race spokes
Rear Tire
Pathfinder Pro 2BR, Tan sidewall, 700x42
Front Tire
Pathfinder Pro 2BR, Tan sidewall, 700x42
SWAT
Integrated SWAT door, internal storage system
Weight
9.52kg (20 lb, 15.8 oz) 56cm
* Specifications are subject to change without notice
Geometry
| 44 | 49 | 52 | 54 | 56 | 58 | 61 | 64 | ||
|---|---|---|---|---|---|---|---|---|---|
| A | Reach | 357 | 365 | 374 | 383 | 392 | 401 | 410 | 419 |
| B | Stack | 568 | 571 | 577 | 592 | 610 | 634 | 659 | 684 |
| C | Head Tube Angle | 69.5° | 70° | 70.5° | 71.25° | 71.75° | 71.75° | 71.75° | 72.25° |
| D | Front Center | 604 | 607 | 614 | 620 | 630 | 647 | 664 | 675 |
| E | Bottom Bracket Drop | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| F | Wheelbase | 1016 | 1019 | 1026 | 1032 | 1042 | 1059 | 1076 | 1088 |
| G | Chainstay Length | 425 | 425 | 425 | 425 | 425 | 425 | 425 | 425 |
| H | Head Tube Length | 99 | 99 | 104 | 116 | 133 | 159 | 185 | 209 |
| I | Top Tube Length | 515 | 529 | 542 | 558 | 573 | 589 | 605 | 628 |
| J | Seat Tube Angle | 74.5° | 74° | 73.75° | 73.5° | 73.5° | 73.5° | 73.5° | 73° |
| K | Standover Height | 683 | 700 | 725 | 754 | 779 | 805 | 832 | 859 |
*All measurements in degrees or millimetres
Sizing Guide
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| 44 | 4'8" - 5'1" | 142 - 155cm |
| 49 | 5'1" - 5'5" | 155 - 163cm |
| 52 | 5'4" - 5'7" | 163 - 170cm |
| 54 | 5'7" - 5'9" | 170 - 175cm |
| 56 | 5'9" - 5'11" | 175 - 180cm |
| 58 | 5'11" - 6'2" | 180 - 188cm |
| 61 | 6'2" - 6'5" | 188 - 196cm |
| 64 | 6'5" - 6'9" | 196 - 205cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
