DESCRIPTION
The Aethos line promises three things—exceptional light weight, perfectly-balanced ride characteristics, and undeniable style—and this Aethos pro is no exception. Aethos: Billions of calculations in the pursuit of one thing—the perfect ride.
Spec’d with Shimano's Ultegra Di2 that delivers clean, crisp shifts and Roval’s Alpinist wheels mated to DT Swiss 350 hubs and your left with a no-fuss build that delivers, mile after mile.
- The Aethos frame has been designed with the perfect combination of ultimate ride feel, light weight, and style—from accelerating up steep pitches and descending technical descents, to all-day saddle comfort on even the longest coffee rides, the Aethos hits the mark. But how, you ask? By reinventing the traditional road shape found on bikes of the past, we’ve subtly altered these shapes to deliver massive gains in stiffness and balance, all without affecting weight or durability. Pair that with an entirely new layup and process that we’ve perfected over multiple decades and you have the lightest frame out there (585 grams, S-Works, size 56cm). The Aethos is more than just a new bike, it’s the first of a new breed.
- A featherweight frame is useless without confidence-inspiring ride characteristics, which is why we’ve developed the Aethos to have the perfect balance of front and rear stiffness combined with exceptional ride quality. By studying the flexing and breathing of carbon fiber, we were able to discover groundbreaking findings about how forces flow through frames. Just a few pedal strokes and you’ll realize this sublime ride sets a new standard.
- Every detail, from the derailleur hangers to the fork expander plug have been designed with style, weight, and durability in mind. We’ve also spec’d it with Roval’s all-new Alpinist carbon seatpost and wheels, further saving weight and improving ride characteristics. Everything in pursuit for the perfect ride.
Specifications
Frame
Aethos FACT 10R Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc
Fork
FACT Carbon, 12x100mm thru-axle, flat-mount disc
Front Brake
Shimano Ultegra R8170, hydraulic disc
Rear Brake
Shimano Ultegra R8170, hydraulic disc
Shift Levers
Shimano Ultegra Di2 R8170
Front Derailleur
Shimano Ultegra Di2 R8150, braze-on
Rear Derailleur
Shimano Ultegra Di2 R8150, 12-speed
Cassette
Shimano Ultegra, 12-speed, 11-30t
Chain
Shimano M8100, 12-speed w/quick link
Crankset
Shimano Ultegra R8100 with 4iiiis Precision 3+ Power Meter
Chainrings
52/36T
Bottom Bracket
Shimano Threaded BSA BB
Front Wheel
Roval Alpinist CL II, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, DT for Roval 350 hub, DT Swiss Aerolite spokes, Tubeless Ready
Rear Wheel
Roval Alpinist CL II, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, DT for Roval 350 hub, DT Swiss Aerolite spokes, Tubeless Ready
Front Tire
S-works Turbo 2BR, 700x28mm
Rear Tire
S-works Turbo 2BR, 700x28mm
Inner Tubes
700x20-28, 48mm Presta Valve
Tape
Supacaz Super Sticky Kush
Stem
Specialized Pro SL, alloy, 4-bolt
Handlebars
S-Works Short & Shallow, 125mm Drop, 75mm Reach w/Di2 Hole
Saddle
Body Geometry Power Pro with Mirror, hollow titanium rails
SeatPost
Roval Alpinist Carbon Seatpost
Seat Binder
Specialized Alloy, 30mm
Weight
6.78kg (14 lb, 15.2 oz) 56cm
* Specifications are subject to change without notice
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | ||
|---|---|---|---|---|---|---|---|
| A | Reach | 375 | 380 | 384 | 395 | 402 | 408 |
| B | Stack | 514 | 527 | 544 | 565 | 591 | 612 |
| C | Head Tube Angle | 71.75° | 72.5° | 73° | 73.5° | 73.5° | 74° |
| D | Front Centre | 574 | 577 | 579 | 591 | 606 | 613 |
| E | Bottom Bracket Drop | 74 | 74 | 72 | 72 | 72 | 72 |
| F | Wheelbase | 973 | 975 | 978 | 991 | 1005 | 1012 |
| G | Chainstay Length | 410 | 410 | 410 | 410 | 410 | 410 |
| H | Head Tube Length | 109 | 120 | 137 | 157 | 184 | 204 |
| I | Top Tube Length | 508 | 531 | 540 | 562 | 577 | 595 |
| J | Seat Tube Angle | 75.5° | 74° | 74° | 73.5° | 73.5° | 73° |
| K | Standover Height | 705 | 728 | 748 | 769 | 796 | 824 |
*All measurements in degrees or millimetres
Size Chart
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| 49 | 5'1" - 5'5" | 155 - 163cm |
| 52 | 5'4" - 5'7" | 163 - 170cm |
| 54 | 5'7" - 5'9" | 170 - 175cm |
| 56 | 5'9" - 5'11" | 175 - 180cm |
| 58 | 5'11" - 6'2" | 180 - 188cm |
| 61 | 6'2" - 6'5" | 188 - 196cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
