DESCRIPTION
The Downhiller's XC Bike
The Tallboy has garnered a dedicated fan base among riders in search of a reliable companion that can withstand the demanding rigors of both intense "power hour" sessions and extended journeys across top-notch trails. With its expertly tuned VPP™ suspension system, the Tallboy seamlessly blends efficient pedaling and the ability to conquer rough terrain. If you ever needed a cross-country bike with the heart of a gravity rider, the Tallboy is your answer.
Specifications
Frame
Carbon C 29" 120mm Travel VPP™
Rear Shock
FOX Float Performance, 190x45
Fork
RockShox Pike Base, 130mm
Rear Derailleur
SRAM NX Eagle, 12spd
Shifter
SRAM NX Eagle, 12spd
Cassette
SRAM PG1230, 12spd, 11-50t
Chain
SRAM NX Eagle, 12spd
Bottom Bracket
SRAM DUB 68/73mm Threaded BB
Headset
FSA IS-2/47/42 ACB or Cane Creek 10 IS Integrated
Rear Tire
Maxxis Forekaster 29"x2.4"WT, 3C, MaxxTerra, EXO
Front Tire
Maxxis Forekaster 29"x2.4"WT, 3C, MaxxTerra, EXO
Front Hub
SRAM MTH 716, 15x110, Torque Cap, 6-Bolt 32h
Front Rim
RaceFace AR Offset 30, 29"
Rear Hub
SRAM MTH 746, 12x148, HG, 6-Bolt, 32h
Rear Rim
RaceFace AR Offset 30, 29"
Front Rotor
Avid Centerline, 180mm
Rear Rotor
Avid Centerline, 180mm
Brakes
SRAM G2 R
Crankset
SRAM Stylo 148 DUB 32t
Handlebar
RaceFace Ride
Stem
Burgtec Enduro MK3, 42mm
Saddle
WTB Silverado, CroMo
Seatpost
SDG Tellis Dropper, 31.6
Grips/Bar Tape
Santa Cruz Bicycles House Grips
* Specifications are subject to change without notice
Geometry
| XS | S | M | L | XL | XXL | ||
|---|---|---|---|---|---|---|---|
| hi/lo | hi/lo | hi/lo | hi/lo | hi/lo | hi/lo | ||
| A | Reach | 405/403 | 430/428 | 455/453 | 475/473 | 495/493 | 520/518 |
| B | Stack | 601/603 | 610/612 | 619/621 | 628/630 | 646/648 | 656/658 |
| C | Head Tube Angle | 65.7/65.5 | 65.7/65.5 | 65.7/65.5 | 65.7/65.5 | 65.7/65.5 | 65.7/65.5 |
| D | Seat Tube Length | 370/370 | 380/380 | 405/405 | 430/430 | 460/460 | 500/500 |
| E | Front Center | 708/708 | 737/737 | 766/766 | 790/790 | 818/818 | 847/847 |
| F | Bottom Bracket Height | 335/332 | 335/332 | 335/332 | 335/332 | 335/332 | 335/332 |
| G | Bottom Bracket Drop | 38/41 | 38/41 | 38/41 | 38/41 | 38/41 | 38/41 |
| H | Wheelbase | 1138/1138 | 1167/1167 | 1199/1199 | 1227/1227 | 1257/1258 | 1290/1291 |
| I | Rear Center | 430/431 | 430/431 | 433/434 | 437/438 | 439/440 | 443/444 |
| J | Head Tube Length | 95/95 | 105/105 | 115/115 | 125/125 | 145/145 | 160/160 |
| K | Top Tube Length | 555/556 | 579/580 | 602/603 | 622/623 | 644/645 | 671/671 |
| L | Seat Tube Angle | 76/75.7 | 76.3/76 | 76.7/76.4 | 76.8/76.6 | 77/76.8 | 77.1/76.8 |
| M | Standover Height | 680/676 | 693/691 | 696/693 | 698/695 | 698/695 | 701/698 |
*All measurements in degrees or millimetres
Sizing
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| XS | 4'8" - 5'1" | 142 - 155cm |
| S | 5'1" - 5'5" | 155 - 165cm |
| M | 5'5" - 5'9" | 165 - 175cm |
| L | 5'9 - 6'1" | 175 - 185cm |
| XL | 6'1" - 6'4" | 185 - 193cm |
| XXL | 6'4" - 6'7" | 193 - 201cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
