DESCRIPTION
A Fair Advantage
We tapped into everything we’ve learned from years of making the highest quality carbon full-suspension bikes and added the super-efficient Superlight™ suspension to make a World Cup-winning XC race bike. The Blur isn’t guaranteed to make you a race winner but being the lightest, full-suspension carbon XC bike we’ve ever made, it might be the difference between claiming first place...or just crossing the line.
Specifications
Frame
Carbon C 29” 108mm -or- 115mm Travel Superlight™ Suspension
Rear Shock
RockShox SidLuxe Select+, 3-Position, w/ Remote, 190x42.5 -or- 190x45
Fork
RockShox Sid SL Select+, 3-Position, 110mm, w/ Remote -or- RockShox Sid Select+, 3-Position, 120mm, w/Remote
Rear Derailleur
SRAM GX Eagle AXS T-Type, 12spd
Shifter
SRAM AXS Pod Bridge
Cassette
SRAM GX Eagle T-Type, 10-52t
Chain
SRAM GX Eagle T-Type, Flattop, 12spd
Chainguide
OneUp Chainguide
Bottom Bracket
SRAM DUB 73mm MTB Wide BB
Headset
Cane Creek 40 IS Integrated Headset
Rear Tire
Maxxis Rekon Race 29"x2.4" 3C MaxxSpeed, EXO
Front Tire
Maxxis Rekon Race 29"x2.4" 3C MaxxSpeed, EXO
Front Hub
DT Swiss 370, 12x110, 6-Bolt, 28h
Front Rim
RaceFace ARC Offset 27 29"
Rear Hub
DT Swis 370, 12x148, XD, 6-Bolt, 36t, 28h
Rear Rim
RaceFace ARC Offset 27 29"
Front Rotor
SRAM HS2 180mm
Rear Rotor
SRAM HS2 180mm
Brakes
SRAM Level Bronze Stealth 4-Piston
Crankset
SRAM GX Eagle DUB T-Type Crankset. 34t
Handlebars
Santa Cruz Carbon Flat Bar, 31.8x760, 7mm Rise
Stem
SRAM Atmos Stem, 60mm
Saddle
SDG Bel-Air V3, Lux-Alloy Atmos
Seatpost
OneUp Dropper Post, 31.6
Grips/Bar Tape
SRAM Twistloc
*Specifications are subject to change without notice
Geometry
| BLUR XC | S | M | L | XL | |
|---|---|---|---|---|---|
| A | Reach | 425 | 450 | 470 | 495 |
| B | Stack | 578.3 | 587.6 | 596.9 | 610.8 |
| C | Head Tube Angle | 68.3° | 68.3° | 68.3° | 68.3° |
| D | Seat Tube Length | 405 | 430 | 470 | 520 |
| E | Front Center | 685.8 | 714.5 | 738.2 | 768.7 |
| F | BB Height | 330.5 | 330.5 | 330.5 | 330.5 |
| G | Bottom Bracket Drop | 42 | 42 | 42 | 42 |
| H | Wheelbase | 1115.8 | 1147 | 1173.2 | 1206.2 |
| I | Rear Center | 430 | 432.5 | 435 | 437.5 |
| J | Head Tube Length | 90 | 100 | 110 | 125 |
| K | Top Tube Length | 563.9 | 592.8 | 616.9 | 647.2 |
| L | Seat Tube Angle | 76.5° | 76.3° | 75.8° | 75.7° |
| M | Standover Height | 736.6 | 740.1 | 739.2 | 745.1 |
*All measurements in degrees or millimetres
Sizing
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| S | 5'1" - 5'5" | 155 - 165cm |
| M | 5'5" - 5'9" | 165 - 175cm |
| L | 5'9 - 6'1" | 175 - 185cm |
| XL | 6'1" - 6'5" | 185 - 196cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
