Light on ounces and heavy on capability, Deluxe Ultimate adds a touch of luxury to the latest uber-capable trail bikes. From the new DebonAir+ air spring that offers more volume tunability than ever to the damper’s independent Low Speed Compression and Rebound adjustments—every aspect was carefully designed to maximize tunability into a streamlined, minimalist package. The power is in your hands to dial in the perfect-for-you, perfect-for-the-trail-ahead settings. A custom-tailored ride, every time.
* Please check with frame manufacturer on Aftermarket rear shock compatibility.
FEATURES
DebonAir+ air spring maximizes fine-tuning potential, allowing you to tune both the negative and positive air volume to perfectly match your bike, desired ride feel, and the trail ahead.
Castled bottom out bumper reduces harsh bottom out, leaving extra room for the bold to go big.
Independent Low Speed Compression and Rebound adjustments give riders the ability to define exactly how the rear shock responds to the trail.
Wider range of Rebound adjustment to accommodate more rider types.
Increased bushing overlap maximizes small bump performance and grip.
Easy access lever to intuitively go between two compression positions—Open or Threshold (firm or lock).
Fresh premium graphics package so your bike looks as dialed it feels.
Top-of-the-line Maxima Plush Dynamic Suspension Lube reduces friction to help maintain traction.
SPECIFICATIONS
DAMPER TYPE RCT
REBOUND TUNE Digressive, Linear, Linear High, Progressive
COMPRESSION TUNE D, H, L, L1, LC, M
LOCKOUT FORCE 320, 380
SHAFT EYELET Bearing, No Bushing, Standard, Trunnion
BODY EYELET Bearing, No Bushing, No Bushing - 90 Deg Rotation, Standard, Standard - 90 Deg Rotation
E-BIKE APPROVED E-bike Approved
WEIGHT 313g
WEIGHT BASED ON 190x45, 1 token, Linear air can, standard/standard
