Why the Van Rysel EDR Ultra?
When distance becomes a playground, the Van Rysel EDR Ultra delivers the ultimate endurance experience. Its high-modulus carbon frame is 6% lighter than before, tipping the scales at just 830 g in size M, making it both efficient and responsive over long rides. Built for ultra-distance comfort, the refined geometry raises the cockpit for a more upright position without sacrificing speed when the pace intensifies. With clearance for 38 mm tires, it’s ready to take on smooth tarmac, weathered roads, or rougher routes with ease—giving you the freedom to ride further, faster, and with lasting confidence.
Geometry
| XS | S | M | L | XL | ||
|---|---|---|---|---|---|---|
| A | Reach | 375 | 380 | 380 | 386 | 388 |
| B | Stack | 524 | 540 | 568 | 601 | 630 |
| C | Head Tube Angle | 70° | 71° | 72° | 73° | 73° |
| D | Bottom Bracket Drop | 67 | 67 | 67 | 67 | 67 |
| E | Wheelbase | 1010 | 1012 | 1015 | 1016 | 1026 |
| F | Chainstay Length | 425 | 425 | 425 | 425 | 425 |
| G | Head Tube Length | 115 | 130 | 155 | 185 | 215 |
| H | Top Tube Length | 515 | 530 | 548 | 564 | 580 |
| I | Seat Tube Angle | 75.1° | 74.6° | 73.5° | 73.5° | 72.9° |
| All measurements in degrees or millimetres | ||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | Imperial | Metric |
|---|---|---|
| XS | 5'1" - 5'5" | 155 - 166cm |
| S | 5'5" - 5'8" | 166 - 173cm |
| M | 5'8" - 5'11" | 173 - 181cm |
| L | 5'11" - 6'1" | 181 - 186 cm |
| XL | 6'1" - 6'5" | 186 - 196cm |
