Specialized S-Works Tarmac SL8 LTD Red Bull 2025 TdF
Specifications
Frame S-Works Tarmac SL8 FACT 12r Carbon, Rider First Engineered, Win Tunnel Engineered, Clean Routing, Threaded BB, 12x142mm thru-axle, flat-mount disc
Fork S-Works FACT 12r Carbon, 12x100mm thru-axle, flat-mount disc
Handlebars Roval Rapide Cockpit, Integrated Bar/Stem w/ Included Accessory Mount
Stem Included in Handlebar
Tape Supacaz Super Sticky Kush
Saddle S-Works Power with Mirror
Seatpost S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset
Front Brake SRAM RED AXS, hydraulic disc
Rear Brake SRAM RED AXS, hydraulic disc
Seat Binder Tarmac integrated wedge
Shift Levers SRAM RED AXS, hydraulic disc
Front Derailleur SRAM RED AXS, braze-on
Rear Derailleur SRAM RED XG-1290, 12-speed
Cassette SRAM RED XG-1290, 12-speed, 10-33t
Chain SRAM RED 12-speed
Crankset SRAM RED AXS Power Meter, 48/35t
Bottom Bracket SRAM DUB BSA 68
Front Wheel Roval Rapide CLX III, Tubeless, 21mm internal width carbon rim, 51 mm depth, Win Tunnel Engineered, Roval LF18F hub, 18h, Arris MTO-255 Straight Pull Spokes (Carbon Fiber reinforced BioNylon, Ti end fittings), White Logo
Rear Wheel Roval Rapide CLX III, Tubeless, 21mm internal width carbon rim, 48.5 mm depth, Win Tunnel Engineered, Roval LF19R hub, 24h, Arris MTO-255 Straight Pull Spokes (Carbon Fiber reinforced BioNylon, Ti end fittings), White Logo
Front Tire S-Works Turbo TLR Race Tire, 700x28c
Rear Tire S-Works Turbo TLR Race Tire, 700x28c
Inner Tubes Standard 80mm Presta valve
Weight 6.64 kg (14 lb, 10.2.3 oz) Weight Size 56cm
Geometry
| 44 | 49 | 52 | 54 | 56 | 58 | 61 | ||
|---|---|---|---|---|---|---|---|---|
| A | Reach | 366 | 375 | 380 | 384 | 395 | 402 | 408 |
| B | Stack | 501 | 514 | 527 | 544 | 565 | 591 | 612 |
| C | Head Tube Angle | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° |
| D | Front Centre | 572 | 574 | 577 | 579 | 592 | 606 | 613 |
| E | Bottom Bracket Drop | 74 | 74 | 74 | 72 | 72 | 72 | 72 |
| F | Wheelbase | 970 | 973 | 975 | 978 | 991 | 1006 | 1013 |
| G | Chainstay Length | 410 | 410 | 410 | 410 | 410 | 410 | 410 |
| H | Head Tube Length | 99 | 109 | 120 | 137 | 157 | 184 | 204 |
| I | Top Tube Length | 496 | 509 | 531 | 541 | 563 | 577 | 595 |
| J | Seat Tube Angle | 75.5° | 75.5° | 75.5° | 75.5° | 75.5° | 75.5° | 75.5° |
| K | Standover Height | 723 | 735 | 746 | 768 | 786 | 808 | 834 |
| All measurements in degrees or millimetres | ||||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | Imperial | Metric |
|---|---|---|
| 44 | 4'8" - 5'1" | 142 - 155cm |
| 49 | 5'1" - 5'5" | 155 - 163cm |
| 52 | 5'4" - 5'7" | 163 - 170cm |
| 54 | 5'7" - 5'9" | 170 - 175cm |
| 56 | 5'9" - 5'11" | 175 - 180cm |
| 58 | 5'11" - 6'2" | 180 - 188cm |
| 61 | 6'2" - 6'5" | 188 - 196cm |
Part Numbers
| Size | Model Number | Red Bull 2025 TdF |
|---|---|
| 44 | 94926-0944 |
| 49 | 94926-0949 |
| 52 | 94926-0952 |
| 54 | 94926-0954 |
| 56 | 94926-0956 |
| 58 | 94926-0958 |
| 61 | 94926-0961 |
