The Best Handling Trail Bike Ever
The 5010 is not just "the little bike" of the Santa Cruz range. It has the magical ability to turn even the most ordinary trails into an adventure, filled with enticing opportunities to leap, skip, and bound. It's as if you possess superhuman skills right at your fingertips. The 5010 has consistently exceeded expectations with its inherent capability, and now, thanks to the added grip from the 29-inch front wheel and further enhanced suspension, it provides you with a refined finesse on the trails.
Frame
Carbon C MX 130mm Travel VPP™
Rear Shock
RockShox Super Deluxe Select+, 210x50
Fork
RockShox Pike Base, 140mm
Rear Derailleur
SRAM NX Eagle, 12spd
Shifter
SRAM NX Eagle, 12spd
Cassette
SRAM PG1230, 12spd, 11-50t
Chain
SRAM NX Eagle, 12spd
Bottom Bracket
SRAM DUB 68/73mm Threaded BB
Headset
FSA IS-2/47/42 ACB
Rear Tire
Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, EXO, TR
Front Tire
Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, TR
Sealant
Reserve Tubeless Sealant
Front Hub
SRAM MTH 716, 15x110, Torque Cap, 6-Bolt 32h
Front Rim
RaceFace AR Offset 30 29"
Rear Hub
SRAM MTH 746, 12x148, HG, 6-Bolt, 32h
Rear Rim
RaceFace AR Offset 30 27.5"
Front Rotor
Avid Centerline 200mm
Rear Rotor
Avid Centerline 180mm
Brakes
SRAM G2 R
Crankset
SRAM Descendant Eagle 148 DUB 32t
Handlebar
Burgtec RideWide Alloy Bar, 800mm
Stem
Burgtec Enduro MK3, 42mm
Saddle
WTB Silverado Medium CroMo
Seatpost
SDG Tellis Dropper, 31.6
Grips/Bar Tape
Santa Cruz Bicycles House Grips
* Specifications are subject to change without notice
XS | S | M | L | XL | XXL | ||
---|---|---|---|---|---|---|---|
hi/lo | hi/lo | hi/lo | hi/lo | hi/lo | hi/lo | ||
A | Reach | 410/406 | 434/431 | 459/456 | 479/476 | 499/496 | 524/521 |
B | Stack | 599/601 | 608/610 | 622/624 | 631/633 | 649/651 | 662/664 |
C | Head Tube Angle | 65.2/64.9 | 65.2/64.9 | 65.2/64.9 | 65.2/64.9 | 65.2/64.9 | 65.1/64.9 |
D | Seat Tube Length | 370 | 380 | 405 | 430 | 460 | 500 |
E | Front Center | 719/718 | 748/748 | 779/779 | 803/803 | 832/832 | 863/863 |
F | Bottom Bracket Height | 338/335 | 338/335 | 338/334 | 338/334 | 338/334 | 338/335 |
G | Bottom Bracket Drop | 16/19 | 16/19 | 16/19 | 16/19 | 16/19 | 16/19 |
H | Wheelbase | 1147/1147 | 1178/1178 | 1212/1213 | 1239/1240 | 1271/1271 | 1305/1306 |
I | Rear Center | 428/429 | 430/431 | 433/434 | 436/437 | 439/440 | 442/443 |
J | Head Tube Length | 90 | 100 | 115 | 125 | 145 | 160 |
K | Top Tube Length | 544/544 | 570/571 | 598/599 | 624/625 | 645/646 | 673/674 |
L | Seat Tube Angle | 77.4/77.1 | 77.4/77.1 | 77.4/77.1 | 77.1/76.8 | 77.3/77 | 77.3/77.1 |
M | Standover Height | 694/688 | 703/698 | 706/700 | 708/703 | 711/706 | 717/712 |
*All measurements in degrees or millimetres
Size | Height | |
---|---|---|
Imperial | Metric | |
XS | 4'8" - 5'1" | 142 - 155cm |
S | 5'1" - 5'5" | 155 - 165cm |
M | 5'5" - 5'9" | 165 - 175cm |
L | 5'9 - 6'1" | 175 - 185cm |
XL | 6'1" - 6'4" | 185 - 193cm |
XXL | 6'4" - 6'7" | 193 - 201cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
