WHY THE CERVÉLO CALEDONIA?
Technical Details
Unlike the Caledonia-5’s fully internal system, the Caledonia offers mechanic-friendly cable and hose routing that supports both fully-integrated setups (with ST31/32 and HB18) and our standard semi-external routing.
- Cleaned up Cable Routing
- Even more tire clearance
- Wet Weather Ready
Geometry
| 48 | 51 | 54 | 56 | 58 | 61 | ||
|---|---|---|---|---|---|---|---|
| A | Reach | 360 | 369 | 378 | 387 | 396 | 405 |
| B | Stack | 505 | 530 | 555 | 580 | 605 | 630 |
| C | Head Tube Angle | 70.5° | 71.5° | 72° | 72° | 72° | 72° |
| D | Front Centre | 580.5 | 582.7 | 592.5 | 609.5 | 627 | 644.1 |
| E | Bottom Bracket Drop | 76.5 | 76.5 | 74 | 74 | 71.5 | 71.5 |
| F | Wheelbase | 983.3 | 985.6 | 996.3 | 1013.4 | 1031.8 | 1048.9 |
| G | Chainstay Length | 415 | 415 | 415 | 415 | 415 | 415 |
| H | Head Tube Length | 89.8 | 110.3 | 136.3 | 162.6 | 191.5 | 217.8 |
| I | Top Tube Length | 502 | 522 | 543 | 565 | 581 | 598 |
| J | Seat Tube Angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| K | Standover Height - 5cm in front of BB | 701 | 743 | 775 | 798 | 824 | 847 |
| All measurements in degrees or millimetres | |||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | Imperial | Metric |
|---|---|---|
| 48 | 4'11" - 5'3" | 150 - 160cm |
| 51 | 5'3" - 5'5" | 160 - 168cm |
| 54 | 5'5" - 5'9" | 168 - 176cm |
| 56 | 5'9 - 6'½" | 176 - 184cm |
| 58 | 6'½" - 6'3" | 184 - 192cm |
| 61 | 6'3" - 6'7" | 192 - 200cm |
