Specialized Turbo Vado SL 2 5.0 EQ
Specifications
Wiring Harness Custom Specialized wiring harness w/ chargeport
Charger Custom charger, 48V System w/ SL system charger plug
UI/Remote Mastermind H3, W/Handlebar Remote, Ant+/Bluetooth®, Built-In System Lock Feature, Integrated Apple Find My, Customizable Display Pages, 2.1"
Motor Specialized 1.2 SL System
Battery Specialized SL2-520, Fully Integrated, 520Wh
Frame 2024 Vado SL
Seat Binder Specialized Alloy 34.9, Steel Bolt
Fork 2024 Vado SL
Front Brake Tektro HD-R510, hydraulic disc, 160mm
Rear Brake Tektro HD-R510, hydraulic disc, 160mm
Chaincase Specialized Custom Chainguard
Chainrings Praxis, Cl 49.8mm, NW, 44T, Bcd 104mm
Cassette Shimano Cues 11-speed, Linkglide 11-50T, CS-LG700
Shift Levers Shimano Cues 11-speed, SL-U8000
Crankset SRAM FC S699 Alloy S-165mm / M-L-170mm / XL-175mm
Chain Shimano 11-speed
Rear Derailleur Shimano Cues 11-speed, RD-U8000
Front Hub Alloy 6 Bolt 28H 12x100mm thru-axle
Rims 700c Double-wall Alloy 27mm internal width
Front Tire Hemisphere Flat Resistant Wirebead All-Terrain Reflect, 700x47c
Rear Tire Hemisphere Flat Resistant Wirebead All-Terrain Reflect, 700x47c
Inner Tubes Standard 40mm SV 29X1.75-2.4
Rear Hub Alloy 6 Bolt 28H 12mm Axle 142mm Spacing
Spokes DT Swiss J-Bend
Saddle Bridge Sport, hollow cr-mo rails, 155mm
Grips ERGON, GA30-S Custom, 134.8mm Length
SeatPost Specialized Alloy, Single Bolt, 30.9mm
Stem Specialized Stealth Stem, Alloy, 31.8mm, Integrated Display And Light Mount, Size S/M : 60mm 17 Deg, L/XL : 75mm 15.5 Deg
Handlebars Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Fenders Specialized custom alloy Fender, Sandblast anodized black finish, 700c, integrated alloy stay
Headlight Lezyne EBike Power STVZO E500+, Integrated Mount
Taillight Spanninga, Stvzo, Commuter Glow With Brake XEr
Pedals Specialized Commuter w/ grip tape & reflectors
Bell Specialized brass bell
Kickstand Specialized kickstand, 40mm mount
Rack Turbo SL Rack, MIK-Compatible, 25kg
Weight - Size MD 20.11 kg (44 lb, 5.4 oz)
Geometry

S | M | L | XL | ||
---|---|---|---|---|---|
A | Reach | 375 | 405 | 430 | 450 |
B | Stack | 600 | 628 | 660 | 698 |
C | Head Tube Angle | 69° | 69° | 69° | 69° |
D | Front Centre | 636 | 676 | 714 | 748 |
E | Bottom Bracket Drop | 70 | 70 | 70 | 70 |
F | Wheelbase | 1092 | 1132 | 1170 | 1204 |
G | Chainstay Length | 465 | 465 | 465 | 465 |
H | Head Tube Length | 156 | 186 | 221 | 261 |
I | Top Tube Length | 547 | 585 | 619 | 650 |
J | Seat Tube Angle | 74° | 74° | 74° | 74° |
K | Standover Height | 755 | 781 | 824 | 869 |
All measurements in millimetres or degrees |
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
Size | Height | |
---|---|---|
Imperial | Metric | |
S | 5'1" - 5'5" | 158 - 165cm |
M | 5'5" - 5'10" | 165 - 178cm |
L | 5'10" - 6'1" | 178 - 185cm |
XL | 6'1" - 6'4" | 185 - 193cm |
