Specialized Turbo Levo SL 2 Comp
Specifications
ChargerCustom charger, 48V System w/ SL system charger plug
MotorSpecialized 1.2 SL Custom RX Trail Tuned Motor, 50Nm power, 320W power
UI/RemoteSpecialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT+/Bluetooth®, w/Handlebar remote
BatterySpecialized SL1-320, fully integrated, 320Wh
StemAlloy Trail Stem, 35mm bar bore
SaddleBridge Comp, Hollow Cr-mo rails, 155/143mm
HandlebarsAlloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S1/S2: 780mm/30mm rise, S3-S6: 800mm/50mm rise
GripsSpecialized Trail Grips
SeatPostX-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 170mm, S6: 190mm
Seat BinderAlloy, 38.6mm
FrameLevo SL carbon Frame, Fact 11m carbon, alloy shock extension, 150mm travel, adjustable head angle, BB height, and compatible with 27.5 or 29" wheels.
ForkFOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset
Rear ShockFOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment, S2-S6:210x55mm, S1: FOX FLOAT Performance 210x52.5mm
Front BrakeSRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Centerline rotor
Rear BrakeSRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Centerline rotor
ChainringsSRAM T-type ring, 32t, alloy
CranksetSRAM Alloy Crankset, 165mm, Dub interface
ChainSRAM 70 Transmission Chain
Shift LeversSRAM AXS POD Controller w/discrete clamp
Rear DerailleurSRAM S-1000 Eagle AXS Transmission
CassetteSRAM 1270 Transmission Cassette, 12 Spd,10-52t
Front HubSpecialized alloy front hub disc, sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 32h
Front TireButcher, GRID TRAIL casing, Gripton T9 compound, 29X2.4
SpokesDT Swiss Elemental
Rear TireEliminator, GRID GRAVITY casing, Gripton T7/T9 compound, 27.5X2.4
Rear HubSpecialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12X148mm thru-axle, 28h, HD Steel Fhb
RimsSpecialized, hookless alloy, 30mm inner width, tubeless ready
Inner TubesStandard, Presta Valve
SWATSWAT CC steerer tube integrated tool with chain tool and link
Weight19.37 kg (42 lb, 11.3 oz) - Size S4
Geometry
| S1 | S2 | S3 | S4 | S5 | S6 | ||
|---|---|---|---|---|---|---|---|
| A | Reach | 405 | 425 | 445 | 470 | 495 | 525 |
| B | Stack | 609 | 617 | 626 | 635 | 645 | 654 |
| C | Head Tube Angle | 64.6° | 64.6° | 64.6° | 64.6° | 64.6° | 64.6° |
| D | Seat Tube Length | 385 | 385 | 405 | 425 | 445 | 465 |
| E | Front Centre | 726 | 752 | 776 | 806 | 835 | 869 |
| F | Bottom Bracket Height | 343 | 348 | 348 | 348 | 348 | 348 |
| G | Bottom Bracket Drop | -34 | -29 | -29 | -29 | -29 | -29 |
| H | Wheelbase | 1158 | 1184 | 1208 | 1238 | 1267 | 1301 |
| I | Chainstay Length | 433 | 432 | 432 | 432 | 432 | 432 |
| J | Head Tube Length | 95 | 100 | 110 | 120 | 130 | 140 |
| K | Top Tube Length | 560 | 582 | 604 | 631 | 659 | 691 |
| L | Seat Tube Angle | 75.8° | 75.8° | 75.8° | 75.8° | 75.8° | 75.8° |
| M | Standover Height | 727 | 763 | 766 | 767 | 773 | 778 |
| All measurements in degrees or millimetres | |||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | Imperial | Metric |
|---|---|---|
| S1 | 4'11" - 5'3" | 150 - 160cm |
| S2 | 5'2" - 5'8" | 157 - 173cm |
| S3 | 5'5" - 5'11" | 165 - 180cm |
| S4 | 5'8" - 6'2" | 173 - 188cm |
| S5 | 5'10" - 6'4" | 178 - 193cm |
| S6 | 6'2" - 6'8" | 188 - 203cm |
Part Numbers
| Size | Model Number | Metallic Obsidian | Pistachio |
|---|---|---|---|
| S1 | 96826-5201 | 96826-5301 | |
| S2 | 96826-5202 | 96826-5302 | |
| S3 | 96826-5203 | 96826-5303 | |
| S4 | 96826-5204 | 96826-5304 | |
| S5 | 96826-5205 | 96826-5305 | |
| S6 | 96826-5206 | 96826-5306 | |
