Specialized Tarmac SL9 S-Level SRAM RED AXS
The Specialized Tarmac SL9 is the fastest road bike ever made. Not just because it’s the lightest. Not just because it’s the most aero. Not because it handles better than anything else on the road. But because it delivers the lowest real-world Time to Finish of any road bike ever made.
If you have any questions do not hesitate to reach out to us and we'll get back to within 24 hours.
Made in Racing
Specialized Tarmac SL9 S-Level SRAM RED AXS
Features
Specifications
| Frame | Tarmac SL9 FACT 10r Carbon, Rider First Engineered, Win Tunnel Engineered, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout |
|---|---|
| Fork | FACT 12r Carbon, 12x100mm thru-axle, flat-mount disc |
| Front Brake | SRAM RED E1, hydraulic disc |
| Rear Brake | SRAM RED E1, hydraulic disc |
| Shift Levers | SRAM RED AXS E1, hydraulic disc |
| Front Derailleur | SRAM RED AXS E1, braze-on |
| Rear Derailleur | SRAM RED AXS E1, 12-speed |
| Cassette | SRAM RED XG-1290 E1, 12-speed, 10-36t |
| Crankset | SRAM RED AXS E1 with Quarq Power Meter, 48/35t |
| Bottom Bracket | SRAM DUB BSA 68 |
| Chain | SRAM RED E1, Flattop |
| Front Wheel | Roval Rapide CL III, Tubeless, 21mm internal width carbon rim, 51mm depth, Win Tunnel Engineered, DT350 hub, 18h, DT Swiss Competition Race Straight Pull Spokes |
| Rear Wheel | Roval Rapide CL III, Tubeless, 21mm internal width carbon rim, 48.5mm depth, Win Tunnel Engineered, DT350 hub, 24h, DT Swiss Competition Race Straight Pull Spokes |
| Front Tire | Cotton TLR, 700x30 |
| Rear Tire | Cotton TLR, 700x30 |
| Inner Tubes | 700x24-34, 80mm presta valve |
| Handlebars | Roval Rapide Cockpit, Integrated Bar/Stem |
| Tape | Supacaz Super Sticky Kush |
| Saddle | Power Pro Mirror, hollow Ti rails |
| Seatpost | S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset |
| Seat Binder | Tarmac integrated wedge |
| Weight | 7.1 kg (15 lb, 10.4 oz) |
| Weight Size | 56 |
*Specifications are subject to change without notice
Geometry
| 44 | 49 | 52 | 54 | 56 | 58 | 61 | ||
|---|---|---|---|---|---|---|---|---|
| A | Reach | 366 | 375 | 380 | 384 | 395 | 402 | 408 |
| B | Stack | 501 | 514 | 527 | 544 | 565 | 591 | 612 |
| C | Head Tube Angle | 70.5° | 71.75° | 72.5° | 72.5° | 73.5° | 73.5° | 74.0° |
| D | Front Centre | 567 | 570 | 572 | 582 | 587 | 602 | 609 |
| E | Bottom Bracket Drop | 74 | 74 | 74 | 72 | 72 | 72 | 72 |
| F | Wheelbase | 970 | 973 | 975 | 986 | 991 | 1006 | 1013 |
| G | Chainstay Length | 410 | 410 | 410 | 410 | 410 | 410 | 410 |
| H | Head Tube Length | 99 | 109 | 120 | 140 | 157 | 184 | 204 |
| I | Top Tube Length | 496 | 509 | 531 | 540 | 563 | 577 | 595 |
| J | Seat Tube Angle | 75.5° | 75.5° | 74.0° | 74.0° | 73.5° | 73.5° | 73.0° |
| K | Standover Height | 722 | 734 | 745 | 767 | 785 | 807 | 833 |
| All measurements in degrees or millimetres | ||||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| 44 | 4'8" - 5'1" | 142 - 155cm |
| 49 | 5'1" - 5'5" | 155 - 163cm |
| 52 | 5'4" - 5'7" | 163 - 170cm |
| 54 | 5'7" - 5'9" | 170 - 175cm |
| 56 | 5'9" - 5'11" | 175 - 180cm |
| 58 | 5'11" - 6'2" | 180 - 188cm |
| 61 | 6'2" - 6'5" | 188 - 196cm |
Model Numbers
| Size | Model Number |
|---|---|
| Gloss Cayenne Metallic / Chrome | |
| 44 | 94927-1144 |
| 49 | 94927-1149 |
| 52 | 94927-1152 |
| 54 | 94927-1154 |
| 56 | 94927-1156 |
| 58 | 94927-1158 |
| 61 | 94927-1161 |
