Specialized CruX  DSW Frameset
Specialized CruX  DSW Frameset

Specialized CruX DSW Frameset

Regular price$2,299.99 CAD
/

Colour
Size

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

The Crux DSW is more than the lightest alloy gravel bike ever made. We took everything we learned creating the carbon Crux and used our patented D’Aluisio Smartweld to make it a reality in alloy. We’ve created the most capable, nimble, balanced, and responsive alloy gravel bike ever made for fast, fun, high-performance riding. And yeah, it’s the lightest too. Some may call it a carbon copy, but we call it the Crux DSW.

Lightest Weight

At just 1399 grams*, the Crux DSW is the lightest alloy gravel frame in the world. Combine that with our Fact12r Crux carbon fork and a build curated for performance, and a complete Crux DSW tips the scales at 9.37kg—no alloy gravel bike can compete.

*56cm in the lightest colourway. Production frames will vary.

Most Capable

More clearance means more capability—that’s why the Crux DSW has the same tire clearance as its carbon sibling—47mm and up to 2.1” on a 650b wheel. Combine this with the tough and light alloy frame, and Crux DSW can take you anywhere you imagine at full gas.

Ultra-Responsive

Responsive at the pedals. Supple in the saddle. We’ve used D’Aluisio Smartweld to fine-tune the properties of alloy to deliver a ride previously impossible without carbon and combine it with the same performance gravel geometry and race-influenced fit as the carbon Crux. A longer reach delivers better weight distribution for quick, confident handling, while a lower stack creates a performance first position. At 72mm of bottom-bracket drop, we hit the sweet spot between nimble and stable.

D’Aluisio Smartweld

D’Aluisio Smartweld - or DSW - is a patented engineering process that uses hydroforming to precisely match tube-to-tube joints for better, stronger welds and, ultimately, a lighter frame that can be twice as durable as a traditional alloy frame. Our Smartweld technique helps us create a unique single-piece downtube and bottom bracket for the Crux, shaving weight and amplifying responsiveness.

  • Lightest: 1399g Crux DSW Frame (raw, unpainted). We took everything we learned creating the carbon Crux and used our patented D’Aluisio Smartweld to make it a reality in alloy. *56cm in the lightest colourway. Production frames will vary.
  • Capable: 47c/650b x 2.1” tire clearance. More clearance means more capability. With Diverge-level tire clearance, Crux takes you anywhere you can imagine.
  • Responsive: Nimble, supple, and reactive. Responsive at the pedals. Supple in the saddle. With performance gravel geometry and race-influenced fit inspired by Crux’s iconic history in ‘cross.

Seat Binder
Specialized Alloy, 30.8mm

Frame
Specialized E5 Premium Aluminum Disc frame with D'Aluisio Smartweld Technology, hydroformed aluminum tubing, tapered head tube, threaded BB

Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc

Weight
1.98kg (4 lb, 5.8 oz)

Weight Size
56

49 52 54 56 58 61
A Reach 375 382 388 397 405 415
B Stack 530 547 560 578 598 621
C Head Tube Angle 70.5° 71.25° 71.5° 72° 72.25° 72.5°
D Front Center 594 600 608 618 630 644
E Bottom Bracket Drop 74 74 72 72 72 72
F Wheelbase 1008 1014 1023 1033 1045 1059
G Chainstay Length 425 425 425 425 425 425
H Head Tube Length 100 115 130 147 167 190
I Top Tube Length 512 539 549 568 582 599
J Seat Tube Angle 75.5° 74° 74° 73.5° 73.5° 73.5°
K Standover Height 749 772 794 816 841 866

*ALL MEASUREMENTS IN DEGREES OR MILLIMETRES

Size Height
Imperial Metric
49 5'1" - 5'5" 155 - 163cm
52 5'4" - 5'7" 163 - 170cm
54 5'7" - 5'9" 170 - 175cm
56 5'9" - 5'11" 175 - 180cm
58 5'11" - 6'2" 180 - 188cm
61 6'2" - 6'5" 188 - 196cm

The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.

We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
