Specialized Crux 5 Frameset
Shipping Canada Wide
Specialized Crux 5 Frameset
$7,499.99
The S-Works Crux 5 is the fastest gravel frame set ever made. Not just because it’s the lightest. Not just because it’s our most aero. Not just because it handles dirt like a Tarmac handles pavement. But because it delivers the lowest real-world Time to Finish of any gravel bike ever made. Crux 5 turns more of your effort into pure speed - validated for real race courses, real terrain, and real riders. When the goal is the top step, nothing in gravel gets you there faster.
210000123004
Have a question?
If you have any questions do not hesitate to reach out to us and we'll get back to within 24 hours.
Features
Time to Finish. The only metric that matters
Specialized's most aerodynamic gravel bike
Nothing is lighter
Specifications
| Frame | S-Works Crux 5 FACT 12r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout |
|---|---|
| Fork | S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc |
| Seatpost | S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset, Lightweight Saddle Clamp |
| Seat Binder | S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset, Lightweight Saddle Clamp |
| Weight | 1.63 kg (3 lb, 9.5 oz) - Size 56 |
*Specifications are subject to change without notice
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | ||
|---|---|---|---|---|---|---|---|
| A | Reach | 375 | 382 | 388 | 400 | 412 | 425 |
| B | Stack | 530 | 547 | 560 | 578 | 598 | 621 |
| C | Head Tube Angle | 70.5° | 70.25° | 71° | 71.5° | 71.5° | 71.5° |
| D | Front Centre | 594 | 604 | 613 | 626 | 644 | 665 |
| E | Bottom Bracket Drop | 80 | 80 | 78 | 78 | 78 | 78 |
| F | Wheelbase | 1008 | 1016 | 1026 | 1039 | 1057 | 1078 |
| G | Chainstay Length | 425 | 425 | 425 | 425 | 425 | 425 |
| H | Head Tube Length | 95 | 110 | 125 | 142 | 163 | 188 |
| I | Top Tube Length | 512 | 534 | 543 | 566 | 583 | 603 |
| J | Seat Tube Angle | 75.5° | 74.5° | 74.5° | 74° | 74° | 74° |
| K | Standover Height | 753 | 766 | 781 | 803 | 823 | 849 |
| All measurements in degrees or millimetres | |||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| 49 | 5'1" - 5'5" | 155 - 163cm |
| 52 | 5'4" - 5'7" | 163 - 170cm |
| 54 | 5'7" - 5'9" | 170 - 175cm |
| 56 | 5'9" - 5'11" | 175 - 180cm |
| 58 | 5'11" - 6'2" | 180 - 188cm |
| 61 | 6'2" - 6'5" | 188 - 196cm |
Model Numbers
| Size | Model Number | ||
|---|---|---|---|
| Agave Grey | Cayenne Metallic | Satin Carbon | |
| 49 | 71427-0149 | 71427-0249 | 71427-0349 |
| 52 | 71427-0152 | 71427-0252 | 71427-0352 |
| 54 | 71427-0154 | 71427-0254 | 71427-0354 |
| 56 | 71427-0156 | 71427-0256 | 71427-0356 |
| 58 | 71427-0158 | 71427-0258 | 71427-0358 |
| 61 | 71427-0161 | 71427-0261 | 71427-0361 |
