Built for Speed
Liv Pique X Advanced SL 2
Local Pickup Only
Contact For Availability
Liv Pique X Advanced SL 2
$7,499.00
Built for riders obsessed with speed, performance, and capability, the new Pique X Advanced SL is engineered to deliver. The flip chip lets you dial in your geometry for any terrain. And with in-frame storage, 130mm fork and 120mm semi-integrated FlexPoint Pro rear suspension, you’re ready for anything, from aggressive climbs and chunky descents, to gutsy lines and all-day epics.
Quick Highlights
- SRAM GX Transmission Drivetrain
- Shimano XT 4-Piston Brakes
- Giant XCR Carbon Wheels
210000129767
Colour
Quantity
Have a question?
If you have any questions do not hesitate to reach out to us and we'll get back to within 24 hours.
Specifications
| Sizes | XS, S, M, L |
|---|---|
| Colour | White/Carbon |
| Frame | Advanced SL-grade composite front and rear triangles, 120mm FlexPoint Pro suspension, flip chip, 12x148mm thru-axle, integrated downtube storage |
| Fork | Fox 34 Rhythm, 130mm, GRIP damper, 44mm offset, Boost 15x110mm |
| Shock | Fox Float SL Performance, 210/50 |
| Handlebar | Giant Contact SL XC Integrated, 9-degree backsweep, 2-degree upsweep |
| Grips | Liv Tactal Pro single lock-on |
| Stem | Giant Contact SL XC Integrated, -8 degree |
| Seatpost |
Giant Contact Switch AT adjustable dropper, remote XS-M: 110-140mm travel / 30.9 x 395mm L: 140-170mm travel / 30.9 x 470mm |
| Saddle | Liv Grit |
| Shifters | SRAM Eagle 90, 1x12 |
| Rear Derailleur | SRAM Eagle 90 transmission |
| Brakes |
Shimano Deore BR-6220, 4-piston, hydraulic Shimano RT-66 rotors [F] 203mm, [R] 180mm |
| Brake Levers | himano Deore BL-M6200 |
| Cassette | SRAM XS-1270 Transmission, 12-speed, 10x52 |
| Chain | SRAM 70 Eagle Transmission |
| Crankset | SRAM 90 Transmission, 30t, 55mm chainline |
| Bottom Bracket | SRAM DUB, press fit |
| Rims |
Giant XCA alloy WheelSystem, 30mm IW, 40mm OW, 21mm H, Wide Guard
technology [F] 29, [R] 29 |
| Hubs |
[F] Giant MTB alloy, 6-bolt, sealed [R] Giant MTB alloy, 120t POE, Helical-Bevel Ratchet Driver, 6-bolt, sealed, HG-driver |
| Spokes | Sapim Laser |
| Tires | Maxxis Rekon Race 29x2.4", folding, EXO, tubeless, 120TPI |
| Extras |
MRP SL TR2 1x chain guide Computer mount Integrated down tube storage bag Tubeless prepared, 2.4" max tire size 34t max chainring size |
*Specifications are subject to change without notice
Geometry
| XS | S | M | L | ||
|---|---|---|---|---|---|
| LO | HI | LO | HI | LO | HI | LO | HI | ||
| A | Reach | 394 | 400 | 410 | 416 | 430 | 436 | 445 | 450 |
| B | Stack | 605 | 602 | 610 | 607 | 620 | 616 | 629 | 625 |
| C | Head Tube Angle | 66.0° | 66.5° | 66.0° | 66.5° | 66.0° | 66.5° | 66.1° | 66.6° |
| D | Bottom Bracket Drop | 48 | 42 | 48 | 42 | 48 | 42 | 48 | 42 |
| E | Wheelbase | 1125 | 1124 | 1143 | 1142 | 1166 | 1166 | 1185 | 1184 |
| F | Chainstay Length | 437 | 435 | 437 | 435 | 437 | 435 | 437 | 435 |
| G | Head Tube Length | 90 | 90 | 95 | 95 | 105 | 105 | 115 | 115 |
| H | Top Tube Length | 557 | 555 | 574 | 572 | 596 | 594 | 613 | 611 |
| I | Seat Tube Angle | 75.0° | 75.5° | 75.0° | 75.5° | 75.0° | 75.5° | 75.1° | 75.6° |
| J | Standover Height | 777 | 784 | 775 | 782 | 770 | 777 | 765 | 771 |
| All measurements in degrees or millimetres | |||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| XS | 4'11" - 5'4" | 150 - 163cm |
| S | 5'2" - 5'7" | 158 - 169cm |
| M | 5'5" - 5'9" | 164 - 175cm |
| L | 5'7" - 5'11" | 170 - 181cm |
Model Numbers
| Size | Model Number |
|---|---|
| White / Carbon | |
| XS | 1072015103 |
| S | 1072015104 |
| M | 1072015105 |
| L | 1072015107 |
