DESCRIPTION
Fast gets Faster
The P5 is a time trial powerhouse designed to maximize speed from start to finish. With 30 years of aerodynamic expertise and input from elite triathletes and Tour de France champions, we refined it with extensive simulations in the CFD metaverse and 3D printed frames. The result? A faster, more adjustable, and—yes—more comfortable racing machine.
The new P5 is notably quicker, saving about 5 watts compared to its predecessor, primarily due to advances in wheel technology like the Reserve 77/88 paired with 29mm Vittoria tires, enhancing aerodynamics and reducing rolling resistance.
Its one-piece front end simplifies assembly and adjustment, allowing stack height adjustments up to 40mm, while lowering the basebar by 10mm for minimized frontal area. The new riser provides tilt adjustments from 0 to 30 degrees in 5-degree steps.
The aerodynamically improved frame supports up to 34mm tires, accommodating the Reserve 77/88 wheels and Vittoria 29mm tires, saving about 4 watts over previous configurations for a total system gain of about 5 watts.
Enhanced comfort features include wider, taller, and thicker armrests and pads, ensuring better control and confidence in the most aerodynamic riding position. The new fastback seat stay design reduces vertical stiffness by 22%, maintaining lateral stiffness for efficient power transfer.
In essence, the new P5 not only enhances speed but also improves rider comfort and control, making it an ideal choice for competitive time trials and triathlons.
Specifications
Fork
Cervélo All-Carbon, Tapered P5 Fork
Headset
FSA IS2 1-1/8 x 1-3/8
Seatpost
Cervélo SP23 Carbon
Left Shifter/Brake
Shimano Dura Ace, R9180, 12 speed
Right Shifter/Brake
Shimano Dura Ace, R9180, 12 speed
Rear Derailleur
Shimano Ultegra, R8150, 12 speed
Front Derailleur
Shimano Ultegra, R8150, 12 speed
Brake Calipers
Shimano Ultegra
Brake Rotors
Shimano CL800 Centerlock
Thru Axles
Cervélo Aero Thru-Axles, 12x100/142
Crankset
Shimano Ultegra R8100, 52/36T, 12 Speed
Bottom Bracket
FSA, BBright thread together, 24mm spindle
Aero Basebar/Extensions
P5 CarbonBasebar/EX14 Riser/Carbon Extensions
Saddle
Prologo Dimesnion Tri TiRox
Cassette
Shimano Ultegra, 11-30, 12 Speed
Chain
Shimano M8100, 12 speed
Front Wheel
Reserve 52, 25.4 IW, Zipp ZR1 ST, 24H, centerlock, tubeless compatible
Rear Wheel
Reserve 63, 24.4mm IW, Zipp ZR1 ST,12x142mm, HG freehub, 24h, centerlock, tubeless compatible
Tire
Corsa Pro Speed TLR 700x29
Tire Alternative
Corsa Pro TLR blk-blk G2.0 OEM 700x29c
Accessories
Smartpak 400, Aerobottle 500, Rear Hydration Mount
*Specifications are subject to change without notice
Geometry
| 48 | 51 | 54 | 56 | 58 | ||
|---|---|---|---|---|---|---|
| A | Reach | 387 | 403 | 417 | 431 | 444 |
| B | Stack | 466 | 486 | 502 | 521 | 539 |
| C | Head Tube Angle | 71° | 72.5° | 72.5° | 72.5° | 72.5° |
| D | Front Center | 582 | 583 | 602 | 622 | 640 |
| E | Bottom Bracket Drop | 75 | 75 | 75 | 75 | 75 |
| F | Wheelbase | 975 | 976 | 995 | 1015 | 1033 |
| G | Head Tube Length | 67.5 | 81 | 98 | 117 | 137 |
| H | Standover Height | 728 | 754 | 769 | 786 | 804 |
*All measurements in degrees or millimetres
