DESCRIPTION
The Caledonia-5 is designed for those who push the limits of endurance cycling, offering a perfect balance between comfort and performance. Whether you're racing traditional Brevets or tackling new ultra-distance challenges like the Transcontinental, the Caledonia-5 is built to excel. Introduced in 2020, this bike quickly became a favourite among athletes who demand both speed and durability from their equipment. The bike's design focuses on long-distance comfort without sacrificing the responsive handling that Cervélo is known for. The addition of in-frame storage, a feature inspired by the P-Series, allows riders to carry essential tools and supplies discreetly and securely.
Refinements to the Caledonia-5 include enhanced comfort features, such as dropped seat stays for increased flexibility and a more compliant ride, making it an ideal choice for rides that stretch into the triple digits on the odometer. Despite these comfort-oriented improvements, the Caledonia-5 maintains the stiffness and pro-level responsiveness required for high-speed racing. It also supports larger tires up to 36mm and includes fender mounts, making it versatile for various riding conditions. Additionally, the Caledonia-5 is UCI approved and comes with a lifetime warranty, ensuring it meets the highest standards of quality and durability.
Features
- Aerodynamics: Completely internal housing and aero tube shapes for free speed, especially beneficial during long rides against the wind.
- In-Frame Storage: Convenient storage compartment for a tube, small multi-tool, and CO2 canister, easily accessible even with gloves.
- Refined Design: Improved comfort and fit adjustments, including a split bearing cap for easy modifications without re-cabling.
- Reserve 42|49 Wheels: Designed with Turbulent Aero technology for all-day capability and aerodynamic efficiency, backed by a lifetime warranty with no-fault crash replacement.
- Geometry: Available in multiple sizes (48, 51, 54, 56, 58, 61) with detailed specifications to fit a wide range of riders.
Specifications
COLOUR
Five Black
FORK
Cervélo All-Carbon, Tapered Caledonia-5 Fork
HEADSET
FSA IS2 1-1/4 x 1-1/2
SEATPOST
Cervélo SP24 Carbon
LEFT SHIFTER/BRAKE
Shimano Dura Ace, R9270, 12 Speed
RIGHT SHIFTER/BRAKE
Shimano Dura Ace, R9270, 12 Speed
REAR DERAILLEUR
Shimano Dura Ace, R9250, 12 Speed
FRONT DERAILLEUR
Shimano Dura Ace, R9250, 12 Speed
BRAKE CALIPERS
Shimano Dura-Ace
BRAKE ROTORS
Shimano CL900 Centerlock
THRU AXLES
Cervélo Aero Thru-Axles, 12x100/142
CRANKSET
Shimano Dura Ace, R9200, 52/36T, 12 Speed
POWER METER
4iiii Precision Pro, GEN3+ Dual Sided
BOTTOM BRACKET
Ceramic Speed, BBright for 24mm spindle
HANDLEBAR
Cervélo HB13 Carbon, 31.8mm clamp
STEM
Cervélo ST31 Carbon
SADDLE
Selle Italia NOVUS BOOST EVO SuperFlow Carbon
CASSETTE
Shimano Dura-Ace, 11-34, 12 Speed
CHAIN
Shimano M9100, 12 Speed
FRONT WHEEL
Reserve 42TA, 25.5mm IW, Zipp ZR1 ST, 24H, centerlock, tubeless compatible
REAR WHEEL
Reserve 49TA, 24.5mm IW, Zipp ZR1 ST,12x142mm, HG freehub, 24H, centerlock, tubeless compatible
TIRE
Corsa Pro Control TLR para-blk-blk G2.0 OEM 700x30c
ACCESSORIES
Cervelo Faceplate Front Computer/ Accessory Mount, Removeable Fender Mounts, Downtube Storage Door with two storage packs
*Specifications are subject to change without notice
Geometry
| 48 | 51 | 54 | 56 | 58 | 61 | ||
|---|---|---|---|---|---|---|---|
| A | Reach | 360 | 369 | 378 | 387 | 396 | 405 |
| B | Stack | 505 | 530 | 555 | 580 | 605 | 630 |
| C | Head Tube Angle | 70.5° | 71.5° | 72° | 72° | 72° | 72° |
| D | Front Centre | 580.5 | 582.7 | 592.5 | 609.5 | 627 | 644.1 |
| E | Bottom Bracket Drop | 76.5 | 76.5 | 74 | 74 | 71.5 | 71.5 |
| F | Wheelbase | 983.2 | 985.6 | 996.3 | 1013.4 | 1031.4 | 1048.9 |
| G | Chainstay Length | 415 | 415 | 415 | 415 | 415 | 415 |
| H | Head Tube Length | 89.8 | 110.3 | 136.3 | 162.6 | 191.5 | 217.8 |
| I | Top Tube Length | 502 | 522 | 543 | 565 | 581 | 598 |
| J | Seat Tube Angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
| K | Standover Height | 701 | 743 | 775 | 798 | 824 | 847 |
*All measurements in degrees or millimetres
Sizing Guide
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| 48 | 4'11" - 5'3" | 150 - 160cm |
| 51 | 5'3" - 5'5" | 160 - 168cm |
| 54 | 5'5" - 5'9" | 168 - 176cm |
| 56 | 5'9 - 6'½" | 176 - 184cm |
| 58 | 6'½" - 6'3" | 184 - 192cm |
| 61 | 6'3" - 6'7" | 192 - 200cm |
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
