CADEX AR 35 Disc Brake Tubeless Wheels
CADEX AR 35 Disc Brake Tubeless Wheels
CADEX AR 35 Disc Brake Tubeless Wheels

CADEX AR 35 Disc Brake Tubeless Wheels

Regular price$1,799.99
/

Wheel

Must purchase Front AND Rear Wheel to receive a complete set

A hookless bead and precision reinforced carbon layup create an exceptionally strong structure with best-in-class weight. A 25mm inner rim width produces a more uniform tire shape and better handling. The innovative 60-tooth ratchet freehub and ultrasmooth ceramic bearings deliver a responsive feel, while high-tensile-strength carbon spokes and Dynamic Balanced Lacing boost lateral stiffness. It all adds up to class-leading speed, efficiency and durability for superior all-road performance.

  • Hookless rim technology offers XC-level impact resistance by providing a more consistent carbon fiber structure at the rim wall. It also creates a
    rounder tyre shape for better grip and sidewall support when cornering.
  • Precision reinforced carbon lay-up places carbon fiber only where needed, creating a super strong and lightweight rim.
  • 25mm inner width and hookless rim construction offer a shorter, wider tyre contact patch for reduced power loss and increased impact absorption.
  • A wide inner width supports higher volume 28–45mm road and gravel tyres, allowing lower tire pressures and more confident handling.
  • High-tensile-strength, ultralight CADEX carbon spokes and precision reinforced carbon lay-up combine for class-leading stiffness-to-weight.
  • Custom tuned Dynamic Balanced Lacing (DBL) technology sets spokes at a wider bracing angle and evens out tension under pedaling force, producing
    a stiffer, more efficient wheel with outstanding power transfer.
  • CADEX ceramic bearings offer 1.5x smoother action than steel.
  • Lightweight CADEX R2-C60 hub with R-Drive features a DLC 60-tooth ratchet driver, durable flat spring and redesigned dust cover for instant engagement and long-lasting efficiency.
  • Integrated front hub design reinforces axle support and eliminates play by replacing end cap, bearing and bushing interface with an integrated
    axle running the length of the hub.

Rim Material: Carbon

Rim Type: Hookless Clincher (Tubeless)

Suggested Tire Size: 700 x 28c - 700 x 45c

Rim Height: 35mm

Rim Outer Width: 31mm

Rim Inner Width: 25mm

ERTO: 622-25

Front Hub: CADEX R2-C60 Hub, Centerlock

Rear Hub: CADEX R2-C60 Hub, 60T Ratchet Drive Centerlock

Freehub System: R-Drive

Bearing: Cadex Ceramic Bearings

Spokes (Front): Aero Carbon Spoke

Lacing (Front): 21H

Lacing (Rear): 24H

Nipple Type: Alloy

Warranty: 2 year warranty

Incident Replacement: 5 year (registered original owner only)

Weight (Pair): 1270g

Item # 350000271 (Front)
Item # 350000282 (Rear)
