Specialized Turbo Levo R Expert
Specifications
Charger Specialized 4amp charger
UI/RemoteMastermind TCU, 2.2" high resolution screen, fully customizeable with Specialized app, works with Apple Find My
Motor Specialized 3.1 Motor, 101Nm torque, 666W power
Battery840Wh battery
Seat BinderAlloy, 38.6mm
Frame FACT 11m Carbon, SWAT downtube storage, 12x148mm UDH compatible rear dropout, side entry battery, adjustable geometry, 130mm of travel
Fork FOX 36 SL Performance Elite, GRIP X Damper, HSC, LSC, LSR adjust, 140mm travel, 44mm offset, 15x110mm
Rear Shock FOX FLOAT Performance Elite GENIE, Ride Dynamics Developed, 2-position compression adjust, 190x45mm
Front Brake SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 200mm rotor
Rear Brake SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 200mm rotor
Chainring SRAM 34t T-Type chainring, 104 BCD, steel
Crankset SRAM GX Alloy Crank, ISIS interface, 55mm chainline, 160mm
Shift Levers SRAM AXS POD Controller
Rear Derailleur SRAM GX Eagle AXS Transmission
Chain SRAM GX Eagle Transmission 12-Speed Flattop Chain
Cassette SRAM GX Transmission, XS 1275, 10-52t
Front Tire Specialized Purgatory, GRID Casing, T9 Compound, 29x2.4
Rear Tire Specialized Purgatory, Grid Trail Casing, T7 Compound, 29x2.4 (S1 27.5x2.4)
Front Wheel Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 1/1 Hub, 15x110mm, 28H, Sapim D-Light Spokes
Rear Wheel Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 1/1 Hub, 12x148mm, 32H, Sapim D-Light Spokes
Inner TubesStandard, Presta Valve
GripsSpecialized Trail Grips
SeatPostX-Fusion Manic, 34.9, S1-S2: 125mm, S3: 150mm, S4: 170mm, S5-S6: 190mm Travel, 0mm offset
HandlebarsSpecialized Alloy, 30mm/40mm rise, 35mm, 800mm wide
SaddleBody Geometry Power Comp, steel rails
StemAlloy Trail Stem, 35mm bar bore
SWATSWAT internal downtube storage
Weight21.76 kg (47 lb, 15.6 oz) - Size S3
Geometry
| S1 | S2 | S3 | S4 | S5 | S6 | |||
|---|---|---|---|---|---|---|---|---|
| A | Reach | 400 | 420 | 450 | 475 | 500 | 525 | |
| B | Stack | 603 | 607 | 617 | 630 | 644 | 657 | |
| C | Headtube Angle | 64.8° | 65.0° | 65.0° | 65.0° | 65.0° | 65.0° | |
| D | Seat Tube Length | 374.92 | 385 | 405 | 425 | 445 | 465 | |
| E | Front Centre | 716 | 736 | 770 | 801 | 833 | 864 | |
| F | Bottom Bracket Height | 339 | 339 | 339 | 339 | 339 | 339 | |
| G | Bottom Bracket Drop | 36.2 | 36.0 | 36.0 | 36.0 | 36.0 | 36.0 | |
| H | Wheelbase | 1161 | 1181 | 1215 | 1246 | 1277 | 1309 | |
| I | Chainstay Length | 447 | 447 | 447 | 447 | 447 | 447 | |
| J | Headtube Length | 96 | 100 | 110 | 125 | 140 | 155 | |
| K | Top Tube Length | 539 | 560 | 592 | 620 | 649 | 677 | |
| L | Seat Tube Angle | 76.91° | 77° | 77° | 77° | 77° | 77° | |
| M | Standover Height | 759 | 765 | 771 | 771 | 778 | 778 | |
| All measurements in degrees or millimetres | ||||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | Imperial | Metric |
|---|---|---|
| S1 | 4'11" - 5'3" | 150 - 160cm |
| S2 | 5'2" - 5'8" | 157 - 173cm |
| S3 | 5'5" - 5'11" | 165 - 180cm |
| S4 | 5'8" - 6'2" | 173 - 188cm |
| S5 | 5'10" - 6'4" | 178 - 193cm |
| S6 | 6'2" - 6'8" | 188 - 203cm |
Part Numbers
| Size | Model Number | Gloss Carbon | Satin Pistachio |
|---|---|---|
| S1 | 95226-3001 | |
| S2 | 95226-3002 | 95226-3102 |
| S3 | 95226-3003 | 95226-3103 |
| S4 | 95226-3004 | 95226-3104 |
| S5 | 95226-3005 | 95226-3105 |
| S6 | 95226-3006 | 95226-3106 |
