Specialized Allez
Specifications
Frame Specialized E5 Premium Aluminum, flat mount disc, fully manipulated tubing w/ SmoothWelds, internal cable routing, threaded BB, 12x142mm thru-axle
Fork Specialized FACT full carbon, flat mount disc, 1-1/8" to 1-3/8" taper, fender eyelets, 12x100mm thru-axle
Front Brake Shimano CUES Hydraulic Brake
Rear Brake Shimano CUES Hydraulic Brake
Cassette Shimano CUES, 11-39T, 10sp
Bottom Bracket Shimano Threaded BSA BB
Crankset Shimano CUES FC-U6030, 50/34T
Chain KMC XGlide
Rear Derailleur Shimano CUES RD-U6020, 10sp
Front Derailleur Shimano CUES FD-U6030, Braze-on
Front Wheel AXIS Sport Disc
Rear Wheel AXIS Sport Disc
Front Tire RoadSport, 700x30
Rear Tire RoadSport, 700x30
Inner Tubes Presta, 700x28-32mm
Saddle Body Geometry Bridge Saddle, steel rails
SeatPost Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Handlebars Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
Tape Supacaz Suave
Stem 3D-forged alloy, 31.8mm, 7-degree rise
Seat Binder Bolt-type, Rack Compatable 31.8mm
Weight 10.0 kg (22 lb, 0.7 oz) – Size 56cm
Geometry
| 44 | 49 | 52 | 54 | 56 | 58 | 61 | |||
|---|---|---|---|---|---|---|---|---|---|
| A | Reach | 356 | 359 | 364 | 370 | 378 | 386 | 392 | |
| B | Stack | 519 | 536 | 552 | 569 | 590 | 610 | 643 | |
| C | Head Tube Angle | 69.5° | 70.5° | 71° | 72° | 72.5° | 73° | 73° | |
| D | Front Centre | 576 | 577 | 583 | 585 | 594 | 603 | 619 | |
| E | Bottom Bracket Drop | 77 | 77 | 77 | 76 | 76 | 74.5 | 74.5 | |
| F | Wheelbase | 984 | 984 | 995 | 998 | 1008 | 1017 | 1033 | |
| G | Chainstay Length | 420 | 420 | 425 | 425 | 425 | 425 | 425 | |
| H | Head Tube Length | 110 | 125 | 140 | 155 | 175 | 195 | 230 | |
| I | Top Tube Length | 493 | 500 | 530 | 541 | 556 | 569 | 586 | |
| J | Seat Tube Length | 430 | 460 | 490 | 510 | 530 | 550 | 580 | |
| K | Standover Height | 715 | 739 | 761 | 781 | 801 | 821 | 852 | |
| All measurements in degrees or millimetres | |||||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Size | Height | |
|---|---|---|
| Imperial | Metric | |
| 44 | 4'8" - 5'1" | 142 - 155cm |
| 49 | 5'1" - 5'5" | 155 - 163cm |
| 52 | 5'4" - 5'7" | 163 - 170cm |
| 54 | 5'7" - 5'9" | 170 - 175cm |
| 56 | 5'9" - 5'11" | 175 - 180cm |
| 58 | 5'11" - 6'2" | 180 - 188cm |
| 61 | 6'2" - 6'5" | 188 - 196cm |
Part Numbers
| Size | Model Number | Obsidian | Maroon | Dune White |
|---|---|---|---|
| 44 | 90026-6044 | 90026-6144 | 90026-6344 |
| 49 | 90026-6049 | 90026-6149 | 90026-6349 |
| 52 | 90026-6052 | 90026-6152 | 90026-6352 |
| 54 | 90026-6054 | 90026-6154 | 90026-6354 |
| 56 | 90026-6056 | 90026-6156 | 90026-6356 |
| 58 | 90026-6058 | 90026-6158 | 90026-6358 |
| 61 | 90026-6061 | 90026-6161 | 90026-6361 |
