Name: Giant Reign Advanced E+ 1
Brand: Giant
SKU: 210000106165
Price: 9999.99 CAD
Availability: OutOfStock

$9,999.99 CAD

Local Pickup Only

Everything about the new Reign Advanced E+ is designed to make it the best descending E-MTB ever. From the bottomless feeling Maestro suspension with 170mm of rear travel (and a 180mm fork) to the punchy new SyncDrive Pro 3 motor and its lightweight, stiff and ultra-adjustable composite frame. We added a titanium skid plate, robust frame protection, and an innovative bash-guard with an elastomer damper—so you can send it with confidence on the most rugged, technical terrain.

Local Pickup Only

[{"id":52348139077939,"title":"Mercury \/ Carbon Smoke \/ S","option1":"Mercury \/ Carbon Smoke","option2":"S","option3":null,"sku":"210000106165","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Giant Reign Advanced  E+ 1 - Mercury \/ Carbon Smoke \/ S","public_title":"Mercury \/ Carbon Smoke \/ S","options":["Mercury \/ Carbon Smoke","S"],"price":999999,"weight":300000,"compare_at_price":null,"inventory_management":"shopify","barcode":"4711291154124","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":52348139110707,"title":"Mercury \/ Carbon Smoke \/ M","option1":"Mercury \/ Carbon Smoke","option2":"M","option3":null,"sku":"210000106166","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Giant Reign Advanced  E+ 1 - Mercury \/ Carbon Smoke \/ M","public_title":"Mercury \/ Carbon Smoke \/ M","options":["Mercury \/ Carbon Smoke","M"],"price":999999,"weight":300000,"compare_at_price":null,"inventory_management":"shopify","barcode":"4711291154131","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":52348139143475,"title":"Mercury \/ Carbon Smoke \/ L","option1":"Mercury \/ Carbon Smoke","option2":"L","option3":null,"sku":"210000106167","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Giant Reign Advanced  E+ 1 - Mercury \/ Carbon Smoke \/ L","public_title":"Mercury \/ Carbon Smoke \/ L","options":["Mercury \/ Carbon Smoke","L"],"price":999999,"weight":300000,"compare_at_price":null,"inventory_management":"shopify","barcode":"4711291154148","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":52348139176243,"title":"Mercury \/ Carbon Smoke \/ XL","option1":"Mercury \/ Carbon Smoke","option2":"XL","option3":null,"sku":"210000106168","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Giant Reign Advanced  E+ 1 - Mercury \/ Carbon Smoke \/ XL","public_title":"Mercury \/ Carbon Smoke \/ XL","options":["Mercury \/ Carbon Smoke","XL"],"price":999999,"weight":300000,"compare_at_price":null,"inventory_management":"shopify","barcode":"4711291154155","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

EMAIL: sales@steedcycles.com

PHONE: 604-987-2168

Description
Specifications
Geometry
Sizing

Giant Reign Advanced E+ 1

Meet the all-new Reign Advanced E+—the bike that redefines what’s possible on the mountain. Born from a passion for the wildest trails and the biggest descents, it’s a machine built to keep you pushing when others back off. The SyncDrive Pro 3 motor surges with seamless support as Maestro suspension soaks up every hit, keeping you in control when the trail turns chaotic. Crafted from lightweight composite and protected by titanium armour, it’s ready for alpine missions, park laps, and everything in between. T

Specifications

MotorSyncDrive Pro3, 48v, 90Nm, powered by Yamaha

ControlsRideControl Ergo 4, 5 power levels plus Smart Assist auto mode

DisplayRideControl GO Lux, full color LCD screen

BatteryEnergyPak Smart 560Wh, integrated, 48V EnergyPak Plus 280 range extender compatible

ChargerEnergyPak 4A, 48V smart charger

FrameAdvanced-grade composite front and rear triangles, 170mm Maestro suspension, flip chip - Maestro 3, 12x148 thru-axle

ForkFox 38 Performance Elite, 180mm, GRIP X2 damper, 44mm offset, 110x15mm, Kabolt X

ShockFox Float X Performance, EVOL Large Volume sleeve, 205/65mm

HandlebarGiant Contact TR, 35mm rise, 35mm

GripsGiant Tactal Pro-E single lock-on

StemGiant Contact SL 35

SeatpostSuspension dropper 30.9mm, travel: 40mm, height adjustment: S/M: 60mm, L/XL: 100mm

SaddleGiant Romero

ShiftersSRAM Eagle 90, 1x12

Rear DerailleurSRAM Eagle 90 Transmission

BrakesTRP EVO DH-R, HD-M846, 4-piston, hydraulic, E2.3 caliper, 4-piston TRP RS01E rotors [F] 220mm, [R] 220mm

Brake LeversTRP EVO DH-R

CassetteSRAM XS-1270 V2 Eagle Transmission, 12-speed, 10x52

ChainSRAM 70 Eagle Transmission

CranksetPraxis e-HD forged alloy crank SRAM Eagle Transmission chain ring, 36t, 104 BCD MRP E-AMg, custom bashguard with integrated damping

RimsGiant TRA WheelSystem, 6069 alloy, welded, 30mm IW, 40mm OW, 21mm H, Wide Guard technology [F] 29, [R] 27.5

HubsGiant TRA, E-Drive 260Nm 6-Pawl Driver, 72t engagement, [F] 110x15mm thru-axle, [R] 148x2mm thru-axle, e-bike optimized

SpokesSapim [F] Race, [R] E-Lite, e-bike optimized

Tires[F] Maxxis Assagai 29x2.5", folding, TLR, EXO+, 3C MaxxGrip [R] Maxxis Minion DHR II 27.5x2.4" WT folding, TLR, DD, 3C MaxxGrip

Extras Tubeless kit (liquid, valves, levers, manual, tool) Inner tube supplied Aegis on-board tire pressure management system

*Specifications are subject to change without notice

Geometry

		S	M	L	XL
		LO \| MID \| HI	LO \| MID \| HI	LO \| MID \| HI	LO \| MID \| HI
A	REACH	426 \| 430 \| 435	456 \| 460 \| 465	476 \| 480 \| 485	505 \| 510 \| 514
B	STACK	647 \| 645 \| 642	656 \| 654 \| 651	669 \| 667 \| 665	683 \| 680 \| 678
C	HEAD TUBE ANGLE	77.1° \| 77.5° \| 77.9°	63.1° \| 63.5° \| 63.9°	63.1° \| 63.5° \| 63.9°	63.1° \| 63.5° \| 63.9°
D	BOTTOM BRACKET DROP	10 \| 5 \| 0	10 \| 5 \| 0	10 \| 5 \| 0	10 \| 5 \| 0
E	WHEELBASE	1226 \| 1226 \| 1227	1261 \| 1261 \| 1261	1287 \| 1288 \| 1288	1323 \| 1323 \| 1324
F	CHAINSTAY LENGTH	450	450	450	450
G	HEAD TUBE LENGTH	95	105	110	135
H	SEAT TUBE LENGTH	400	425	450	475
I	SEAT TUBE ANGLE	77.1° \| 77.5° \| 77.9°	77.1° \| 77.5° \| 77.9°	77.1° \| 77.5° \| 77.9°	77.1° \| 77.5° \| 77.9°
All measurements in degrees or millimetres

Sizing Guide

The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.

We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.

Start a chat with our team

Size	Height
	Imperial	Metric
S	5'4" - 5'9"	163- 174cm
M	5'7" - 6'0"	171 - 188cm
L	5'10" - 6'3"	179 - 188cm
XL	6'2" - 6'6"	187 - 198cm

		S	M	L	XL
		LO \| MID \| HI	LO \| MID \| HI	LO \| MID \| HI	LO \| MID \| HI
A	REACH	426 \| 430 \| 435	456 \| 460 \| 465	476 \| 480 \| 485	505 \| 510 \| 514
B	STACK	647 \| 645 \| 642	656 \| 654 \| 651	669 \| 667 \| 665	683 \| 680 \| 678
C	HEAD TUBE ANGLE	77.1° \| 77.5° \| 77.9°	63.1° \| 63.5° \| 63.9°	63.1° \| 63.5° \| 63.9°	63.1° \| 63.5° \| 63.9°
D	BOTTOM BRACKET DROP	10 \| 5 \| 0	10 \| 5 \| 0	10 \| 5 \| 0	10 \| 5 \| 0
E	WHEELBASE	1226 \| 1226 \| 1227	1261 \| 1261 \| 1261	1287 \| 1288 \| 1288	1323 \| 1323 \| 1324
F	CHAINSTAY LENGTH	450	450	450	450
G	HEAD TUBE LENGTH	95	105	110	135
H	SEAT TUBE LENGTH	400	425	450	475
I	SEAT TUBE ANGLE	77.1° \| 77.5° \| 77.9°	77.1° \| 77.5° \| 77.9°	77.1° \| 77.5° \| 77.9°	77.1° \| 77.5° \| 77.9°
All measurements in degrees or millimetres
