Mange ma poussière
Specialized S-Works Crux 5 LTD conçu pour les légendes
Libérez votre potentiel en gravel avec le S-Works Crux. Son cadre et sa fourche légers en carbone FACT 12r, son groupe SRAM RED AXS XPLR et ses roues Roval Terra Aero CLX offrent vitesse, fiabilité et polyvalence pour chaque aventure épique.
If you have any questions do not hesitate to reach out to us and we'll get back to within 24 hours.
Mange ma poussière
Specialized S-Works Crux 5 LTD conçu pour les légendes
Features
Specifications
| FRAME | S-Works Crux 5 FACT 12r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout |
|---|---|
| FORK | S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc |
| FRONT BRAKE | SRAM RED E1, hydraulic disc |
| REAR BRAKE | SRAM RED E1, hydraulic disc |
| SHIFT LEVERS | SRAM RED AXS E1, hydraulic disc |
| REAR DERAILLEUR | SRAM RED AXS XPLR E1, 13-speed |
| CASSETTE | SRAM RED XPLR E1, 13-speed, 10-46t |
| CHAIN | SRAM RED E1 |
| CRANKSET | SRAM RED XPLR E1, Aero-X Sync chainring with Quarq power meter, 44t |
| BOTTOM BRACKET | Ceramic Speed BB Alpha, BSA DUB |
| FRONT TIRE | Pathfinder 700x45, Tubeless Ready |
| FRONT WHEEL | Roval Terra Aero CLX, 27mm internal width, tubeless ready, 50mm depth, 18h, Roval LF18-F hub with ceramic SINC bearings, Centerlock disc, Roval by ARRIS, Composite Aero Spoke with Ti End Pieces |
| REAR TIRE | Pathfinder 700x45, Tubeless Ready |
| REAR WHEEL | Roval Terra Aero CLX, 27mm internal width, tubeless ready, 50mm depth, 18h, Roval LF18-F hub with ceramic SINC bearings, Centerlock disc, Roval by ARRIS, Composite Aero Spoke with Ti End Pieces |
| INNER TUBES | 700x32-50mm, 60mm Presta valve |
| STEM | Included in Handlebar |
| HANDLEBARS | Roval Terra Cockpit, Integrated Bar/Stem |
| TAPE | Supacaz Super Sticky Kush |
| SADDLE | S-Works Power with Mirror |
| SEATPOST | S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset, Lightweight Saddle Clamp |
| SEAT BINDER | Integrated Wedge |
| WEIGHT | 7.1 kg (15 lb, 10.4 oz) - Size 56 |
*Les spécifications sont susceptibles d’être modifiées sans préavis
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | ||
|---|---|---|---|---|---|---|---|
| A | Reach | 375 | 382 | 388 | 400 | 412 | 425 |
| B | Stack | 530 | 547 | 560 | 578 | 598 | 621 |
| C | Angle de direction | 70,5° | 70,25° | 71° | 71,5° | 71,5° | 71,5° |
| D | Longueur de la base avant | 594 | 604 | 613 | 626 | 644 | 665 |
| E | Hauteur du boitier de pédalier | 80 | 80 | 78 | 78 | 78 | 78 |
| F | Empattement | 1008 | 1016 | 1026 | 1039 | 1057 | 1078 |
| G | Longueur bases | 425 | 425 | 425 | 425 | 425 | 425 |
| H | Hauteur de direction | 95 | 110 | 125 | 142 | 163 | 188 |
| I | Longueur du tube horizontal | 512 | 534 | 543 | 566 | 583 | 603 |
| J | Angle du tube de selle | 75,5° | 74,5° | 74,5° | 74° | 74° | 74° |
| K | Hauteur de surplomb | 753 | 766 | 781 | 803 | 823 | 849 |
| Toutes les mesures en degrés ou millimètres | |||||||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Taille | Hauteur | |
|---|---|---|
| Impérial | Métrique | |
| 49 | 5'1" - 5'5" | 155 - 163cm |
| 52 | 5'4" - 5'7" | 163 - 170cm |
| 54 | 5'7" - 5'9" | 170 - 175cm |
| 56 | 5'9" - 5'11" | 175 - 180cm |
| 58 | 5'11" - 6'2" | 180 - 188cm |
| 61 | 6'2" - 6'5" | 188 - 196cm |
Model Numbers
| Size | Model Number | Made in Racing Red |
|---|---|
| 49 | 91427-0249 |
| 52 | 91427-0252 |
| 54 | 91427-0254 |
| 56 | 91427-0256 |
| 58 | 91427-0258 |
| 61 | 91427-0261 |
