Chromag Jus
Specifications
Fourche Manitou Machete, 100mm
Potence Chromag HiFi BSX 31mm
Barre Chromag Vanguard, 720mm, 31.8mm
Jeu de direction FSA 1-1/8" 1.5" Intégré
Pédalier SAMOX, 127mm, 30t 76BCD
Frein Niveau SRAM
Rotor SRAM 140mm
Manette SRAM GX Eagle
Cassette 16t ou 14t
Jantes Ally Chromag
Moyeux D1 Chromag
Pneus Kenda K RAD
Tige de selle Bassix Chromag
Selle Ouverture Chromag
Poignées Format Chromag
Chaîne KMC
Pédales Non inclus
Geometry
| 20" | 24" | ||
|---|---|---|---|
| A | Reach | 334 | 375 |
| B | Stack | 443 | 484 |
| C | Angle de direction | 67° | 67° |
| D | Hauteur du boitier de pédalier | 0 | 20 |
| E | Empattement | 876 | 984 |
| F | Longueur bases | 310 | 360 |
| G | Hauteur de direction | 85 | 85 |
| H | Longueur du tube horizontal | 454 | 510 |
| I | Angle du tube de selle | 75° | 75° |
| H | Hauteur de surplomb | 497 | 548 |
| Toutes les mesures en degrés ou millimètres | |||
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
| Taille | Taille | |
|---|---|---|
| Impérial | Métrique | |
| 20" | 3'7" - 4'5" | 109 - 135cm |
| 24" | 4'3" - 5'1" | 130 - 155cm |
