Specialized Demo Race
Specifications
Frame M5 alloy, Style-Specific DH Geometry, horst pivot flip chip for 27.5 or 29 rear wheel, BSA threaded BB, full internal cable routing with option for full external brake, 148mm rear spacing, sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm of travel
Seat Binder Alloy, 34.9mm
Fork Öhlins DH38 M.1 29, TTX Twin Tube Damping, external low speed rebound adjust, external high and low speed compression adjustment, 20x110mm, 58mm offset, 200mm of travel
Rear Shock Öhlins TTX22M.2 Coil, external rebound adjust, external high and low speed compression adjustment, Trunnion mount, 225x75
Front Brake SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, 220mm
Rear Brake SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, 200mm
Bottom Bracket SRAM DUB, 83mm
Crankset SRAM X01 DH, DUB, carbon, Direct mount ring, 165mm
Rear Derailleur SRAM X01 DH, 7-speed, trigger
Shift Levers SRAM X01 DH, trigger, 7-speed
Cassette SRAM X01 DH, 7-speed, 10-24t
Chain Sram PC1130 w/Powerlink, 11-speed
Crankset SRAM X01 DH, DUB, carbon, Direct mount ring, 165mm
Rear Hub DT Swiss 350 hub, 12x148mm
Front Hub DT Swiss 350 hub, 20x110mm
Spokes Sapim D-Light
Front Tire Cannibal, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.4"
Rims Roval Traverse Alloy 29" / 27.5", 32h alloy rim, 28mm inner rim width
Rear Tire Cannibal, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.4"
Inner Tubes Standard Presta
Stem Renthal Integra 35mm Direct Mount Stem, 45mm length
SeatPost Thomson, alloy, straight, 12-degree clamp
Handlebars Renthal Fatbar 35, 5-degree upsweep, 7-degree backsweep, 30mm rise, 800mm, 35.0mm
Grips Deity Lockjaw
Saddle Body Geometry Henge DH, hollow titanium rails, 130mm
Weight 17.62kg (38 lb, 13.5 oz) S3
Geometry

S2 | S3 | S4 | ||||
---|---|---|---|---|---|---|
A | Reach | 426 | 446 | 466 | ||
B | Stack | 632 | 632 | 632 | ||
C | Head Tube Angle | 62.8° | 62.8° | 62.8° | ||
D | Seat Tube Length | 394 | 420 | 420 | ||
E | Front Center | 801 | 821 | 841 | ||
F | Bottom Bracket Height | 350 | 350 | 350 | ||
G | Bottom Bracket Drop | 25 | 25 | 25 | ||
H | Wheelbase | 1249 | 1269 | 1289 | ||
I | Chainstay Length | 438 | 438 | 438 | ||
J | Head Tube Length | 105 | 105 | 105 | ||
L | Seat Tube Angle | 77.8° | 76.4° | 76.4° | ||
ALL MEASUREMENTS IN DEGREES OR MILLIMETRES |
Sizing Guide
The sizing chart is a great place to start when picking your next bike but everyone will fit a bike a bit differently. Your torso, arm, and leg lengths all play into what size of bike you may need. Plus, there's your own personal preference.
We always recommend swinging by the shop and taking the bike that you're looking for a spin to see how it feels. If you're unable to come by, looking at the geometry of your current bike and comparing it is a good place to start. If you have any further questions, our customer service team is there to help.
Size | Height | |
---|---|---|
Imperial | Metric | |
S2 | 5'2" - 5'9" | 158 - 175cm |
S3 | 5'5" - 6'0" | 165 - 183cm |
S4 | 5'8" - 6'4" | 173 - 193cm |
